Workflow automation with

Nextflow and Flowcraft

GIP Research Meeting

@ines_cim

cimendes

Inês Mendes

Do I know what is happening?
Is it reproducible?
Is it shareable?

Reproducibility

| The questions

Black

Box

Transparent

Box

Commercial/Freeware
You get what it gives you
Ready to use
Stealth change
Standalone

Freeware
You can "tailor"
"Major" headache
Visible change
Dependencies

The needs:

Analyze a large amount of sequence data routinely
Some computationally intensive steps
Constantly updating/adding software

Reproducibility

| The needs

Reproducibility

| The challenges

No standard way of describing experiments, environments, (derived) data, and workflows.

No transparency in creating environments and steps/methods to recreate analysis.

The experimental nature of the research code and ecosystem makes it often hard to build.

Unresolved or undocumented dependencies.

Infrastructure for storage and distribution.

Software Containers

Runs the same regardless of the environment.

Enables the distribution and deployment of scientific software in a runnable state.

A container image is a lightweight, stand-alone, executable package of a software that includes everything needed to run it:

code
runtime
system tools
system libraries

| What is it?

Host Hardware

Container Engine

Host OS

Hypervisor

Guest OS

App

Guest OS

VM1

VM2

App

Virtual Machines

Containers

Software Containers

| VMs and Containers

Software Containers

| Solutions

Docker Hub

build

pull & run

host

push

Nextflow

| What is it?

Enables scalable and reproducible scientific workflows using software containers. It simplifies the deployment of complex parallel and reactive workflows.

Reactive workflow framework

Create pipelines with asynchronous (and implicitly parallelized) data streams

Programing DSL

Has its own language for building a pipeline

Containerized

Out of the box integration with containers engines (Docker, Singularity, Shifter)

Nextflow

| Requirements

Installation

Bash

Ubiquitous on UNIX. Windows: Cygwin or Linux sysbsystem, maybe...

Java 1.8

sudo apt-get install openjdk-8-jdk

Nextflow

curl -s https://get.nextflow.io | bash

Optional (but recommended)

Container engine (Docker, Singularity...)

The creation of Nextflow pipelines was designed for bioinformaticians familiar with programming.

It's execution is for everyone.

Nextflow

| Why bother?

Automatic management of temporary input/output directory/files

No need for custom handling of concurrency (parallelization)

A single pipeline can support any scripting language (Bash, Python, Perl, R...)

Every process (task) can be run in a container

It's portability allows for the same pipeline to run on a laptop, server, cluster, etc

Checkpoints and resume functionality

Steaming capability

Host pipeline on GitHub and run remotely

FlowCraft

| The motivation

The game changing combination of nextflow + containers:

Portability
Reproducible
Scalability
Multi-scale containerization
Native cloud support

Substantial challenges still persist:

Fast pace of bioinformatics software landscape
Continuous need for benchmarking and comparative analyses
The need for agile and dynamic pipeline building
Remove the pain of changing inner workings of workflows

FlowCraft

| The premise

Workflow based development

Component based development

Components are modular pieces of nextflow code with some basic rules:

Component A

- Input/Output

- Parameters

- Resources

Component B

- Input/Output

- Parameters

- Resources

FlowCraft

| The premise

With this framework, building workflows becomes simple:

flowcraft build -t 'trimmomatic fastqc spades pilon' -o my_nextflow_pipeline

Results in the following workflow DAG

$ nextflow run my_nextflow_pipeline.nf --help
N E X T F L O W  ~  version 0.32.0
Launching `my_nextflow_pipeline.nf` [jovial_swirles] - revision: b4473f5a12

============================================================
                F L O W C R A F T
============================================================
Built using flowcraft v1.4.0


Usage:
    nextflow run my_nextflow_pipeline.nf

       --fastq                     Path expression to paired-end fastq files. (default: fastq/*_{1,2}.*) (default: 'fastq/*_{1,2}.*')

       Component 'INTEGRITY_COVERAGE_1_1'
       ----------------------------------
       --genomeSize_1_1            Genome size estimate for the samples in Mb. It is used to estimate the coverage and other assembly parameters andchecks (default: 1)
       --minCoverage_1_1           Minimum coverage for a sample to proceed. By default it's setto 0 to allow any coverage (default: 0)

       Component 'TRIMMOMATIC_1_2'
       ---------------------------
       --adapters_1_2              Path to adapters files, if any. (default: 'None')
       --trimSlidingWindow_1_2     Perform sliding window trimming, cutting once the average quality within the window falls below a threshold (default: '5:20')
       --trimLeading_1_2           Cut bases off the start of a read, if below a threshold quality (default: 3)
       --trimTrailing_1_2          Cut bases of the end of a read, if below a threshold quality (default: 3)
       --trimMinLength_1_2         Drop the read if it is below a specified length  (default: 55)
       --clearInput_1_2            Permanently removes temporary input files. This option is only useful to remove temporary files in large workflows and prevents nextflow's resume functionality. Use with caution. (default: false)

       Component 'FASTQC_1_3'
       ----------------------
       --adapters_1_3              Path to adapters files, if any. (default: 'None')

       Component 'SPADES_1_4'
       ----------------------
       --spadesMinCoverage_1_4     The minimum number of reads to consider an edge in the de Bruijn graph during the assembly (default: 2)
       --spadesMinKmerCoverage_1_4 Minimum contigs K-mer coverage. After assembly only keep contigs with reported k-mer coverage equal or above this value (default: 2)
       --spadesKmers_1_4           If 'auto' the SPAdes k-mer lengths will be determined from the maximum read length of each assembly. If 'default', SPAdes will use the default k-mer lengths.  (default: 'auto')
       --clearInput_1_4            Permanently removes temporary input files. This option is only useful to remove temporary files in large workflows and prevents nextflow's resume functionality. Use with caution. (default: false)
       --disableRR_1_4             disables repeat resolution stage of assembling. (default: false)

       Component 'ASSEMBLY_MAPPING_1_5'
       --------------------------------
       --minAssemblyCoverage_1_5   In auto, the default minimum coverage for each assembled contig is 1/3 of the assembly mean coverage or 10x, if the mean coverage is below 10x (default: 'auto')
       --AMaxContigs_1_5           A warning is issued if the number of contigs is overthis threshold. (default: 100)
       --genomeSize_1_5            Genome size estimate for the samples. It is used to check the ratio of contig number per genome MB (default: 2.1)

       Component 'PILON_1_6'
       ---------------------
       --clearInput_1_6            Permanently removes temporary input files. This option is only useful to remove temporary files in large workflows and prevents nextflow's resume functionality. Use with caution. (default: false)

Help and parameters tailor-made to the pipeline

FlowCraft

| The premise

It's easy to get experimental:

flowcraft build -t 'trimmomatic fastqc skesa pilon' -o my_nextflow_pipeline

Switch spades for skesa

flowcraft build -t 'trimmomatic fastqc skesa pilon (abricate | prokka)' -o my_nextflow_pipeline

Add genome annotation components in the end

FlowCraft

| The premise

It's easy to get wild:

flowcraft build -t 'reads_download (
    spades | skesa pilon (abricate | chewbbaca) | megahit |
    fastqc_trimmomatic fastqc (spades pilon (
        mlst | prokka | chewbbaca) | skesa pilon abricate))'
     -o my_nextflow_pipeline

wait, what?
