Build, monitor and report Nextflow pipelines made easy

Applied Bioinformatics and Public Health Microbiology

@ines_cim

cimendes

Inês Mendes

05 - 07 June 2019

FlowCraft

 | The motivation

The game changing combination of nextflow + containers:

  • Portability
  • Reproducible
  • Scalability
  • Multi-scale containerization
  • Native cloud support

Substantial challenges still persist:

  • Fast pace of bioinformatics software landscape
  • Continuous need for benchmarking and comparative analyses
  • The need for agile and dynamic pipeline building
  • Remove the pain of changing inner workings of workflows

FlowCraft

 | The premise

Workflow based development

Component based development

Components are modular pieces of nextflow code with some basic rules:

Component A

- Input/Output

- Parameters

- Resources

Component B

- Input/Output

- Parameters

- Resources

FlowCraft

 | The premise

With this framework, building workflows becomes simple:

flowcraft build -t 'trimmomatic fastqc spades pilon' -o my_nextflow_pipeline

Results in the following workflow DAG

$ nextflow run my_nextflow_pipeline.nf --help
N E X T F L O W  ~  version 0.32.0
Launching `my_nextflow_pipeline.nf` [jovial_swirles] - revision: b4473f5a12

============================================================
                F L O W C R A F T
============================================================
Built using flowcraft v1.4.0


Usage:
    nextflow run my_nextflow_pipeline.nf

       --fastq                     Path expression to paired-end fastq files. (default: fastq/*_{1,2}.*) (default: 'fastq/*_{1,2}.*')

       Component 'INTEGRITY_COVERAGE_1_1'
       ----------------------------------
       --genomeSize_1_1            Genome size estimate for the samples in Mb. It is used to estimate the coverage and other assembly parameters andchecks (default: 1)
       --minCoverage_1_1           Minimum coverage for a sample to proceed. By default it's setto 0 to allow any coverage (default: 0)

       Component 'TRIMMOMATIC_1_2'
       ---------------------------
       --adapters_1_2              Path to adapters files, if any. (default: 'None')
       --trimSlidingWindow_1_2     Perform sliding window trimming, cutting once the average quality within the window falls below a threshold (default: '5:20')
       --trimLeading_1_2           Cut bases off the start of a read, if below a threshold quality (default: 3)
       --trimTrailing_1_2          Cut bases of the end of a read, if below a threshold quality (default: 3)
       --trimMinLength_1_2         Drop the read if it is below a specified length  (default: 55)
       --clearInput_1_2            Permanently removes temporary input files. This option is only useful to remove temporary files in large workflows and prevents nextflow's resume functionality. Use with caution. (default: false)

       Component 'FASTQC_1_3'
       ----------------------
       --adapters_1_3              Path to adapters files, if any. (default: 'None')

       Component 'SPADES_1_4'
       ----------------------
       --spadesMinCoverage_1_4     The minimum number of reads to consider an edge in the de Bruijn graph during the assembly (default: 2)
       --spadesMinKmerCoverage_1_4 Minimum contigs K-mer coverage. After assembly only keep contigs with reported k-mer coverage equal or above this value (default: 2)
       --spadesKmers_1_4           If 'auto' the SPAdes k-mer lengths will be determined from the maximum read length of each assembly. If 'default', SPAdes will use the default k-mer lengths.  (default: 'auto')
       --clearInput_1_4            Permanently removes temporary input files. This option is only useful to remove temporary files in large workflows and prevents nextflow's resume functionality. Use with caution. (default: false)
       --disableRR_1_4             disables repeat resolution stage of assembling. (default: false)

       Component 'ASSEMBLY_MAPPING_1_5'
       --------------------------------
       --minAssemblyCoverage_1_5   In auto, the default minimum coverage for each assembled contig is 1/3 of the assembly mean coverage or 10x, if the mean coverage is below 10x (default: 'auto')
       --AMaxContigs_1_5           A warning is issued if the number of contigs is overthis threshold. (default: 100)
       --genomeSize_1_5            Genome size estimate for the samples. It is used to check the ratio of contig number per genome MB (default: 2.1)

       Component 'PILON_1_6'
       ---------------------
       --clearInput_1_6            Permanently removes temporary input files. This option is only useful to remove temporary files in large workflows and prevents nextflow's resume functionality. Use with caution. (default: false)

Help and parameters tailor-made to the pipeline

FlowCraft

 | The premise

It's easy to get wild:

flowcraft build -t 'reads_download (
    spades | skesa pilon (abricate | chewbbaca) | megahit |
    fastqc_trimmomatic fastqc (spades pilon (
        mlst | prokka | chewbbaca) | skesa pilon abricate))'
     -o my_nextflow_pipeline

wait, what?

FlowCraft

 | Building features

Forks

Connect one component to multiple

Secondary channels

Connect non-adjacent components

Extra inputs

Inject user input data anywhere

Recipes

Curated and pre-assembled pipelines for specific needs

Multiple Raw Input Types

Not limited to paired-end FastQ or Fasta

Dynamic Input in Components

One component, multiple inputs

Expand Building Features

New merge operators

  • Component that receives multiple input types
  • Component that merges multiple inputs from different branches

FlowCraft

 | The future

FlowCraft

 | In action

FlowCraft

 | The team

Diogo N Silva

Tiago F Jesus

Inês Mendes

Bruno

Ribeiro-Gonçalves

Core developers

Advisors

Prof. Mário Ramirez

Prof. João A Carriço

Watch the demo!

Join the fun!

conda install flowcraft

FCT PhD Grant SFRH/BD/129483/2017

BacGenTrack project [FCT / Scientific and Technological Research Council of Turkey, TUBITAK/0004/2014]

Funding and Acknowledgements

brew install brewsci/bio/flowcraft
pip install flowcraft
