Taller de contribución a

Jesus Lerma

Lee Calcote

Jesus Lerma

Lee Calcote

@shlerma

@lcalcote

Contributor, Meshery

Maintainer, Layer5

Ameya Agashe

@ameyamagashe

Contributor, Layer5

Thank you to our lab assistants!

Segment 1 (5:30pm-6:30pm)

  • Introduction to Service Meshes and Meshery



Segment 2 (6:30pm-7:30pm)

  • How to Contribute to Meshery



Segment 3 (7:30pm-8:30pm)

  • Translating and Contributing to Meshery Docs and other Layer5 projects

Agenda

Prerequisites: Access to Docker and Kubernetes
Technologies you will use: Docker, Kubernetes, Meshery
Description: Introduction to Service Mesh. How to use Meshery to evaluate and operate 8 different service meshes.

Technologies Used: Golang

Description: How to contribute to `mesheryctl` and the Meshery project.

Technologies Used: Jekyll

Description: How to contribute to Meshery Documentation

What is a Service Mesh?

a services-first network

layer5.io/books/the-enterprise-path-to-service-mesh-architectures

@lcalcote

Traffic Control

control over chaos

Resilency

content-based traffic steering

Observability

what gets people hooked on service metrics

Security

identity and policy

Service Mesh Functionality

Expect more from your infrastructure

Business Logic

in-network application logic

@lcalcote

Reviews v1

Reviews Pod

Reviews v2

Reviews v3

Product Pod

Details Container

Details Pod

Ratings Container

Ratings Pod

Product Container

Reviews Service

Ratings Service

Details Service

Product Service

BookInfo Sample App

@lcalcote

BookInfo Sample App on Service Mesh

Reviews v1

Reviews Pod

Reviews v2

Reviews v3

Product Pod

Details Container

Details Pod

Ratings Container

Ratings Pod

Product Container

Envoy sidecar

Envoy sidecar

Envoy sidecar

Envoy sidecar

Envoy sidecar

Reviews Service

Enovy sidecar

Envoy ingress

Product Service

Ratings Service

Details Service

@lcalcote

Observability

what gets people hooked on service metrics

Goals

  • Metrics without instrumenting apps

  • Consistent metrics across fleet

  • Trace flow of requests across services

  • Portable across metric back-end providers

You get a metric!  You get a metric!  Everyone gets a metric!

@lcalcote

Traffic Control

control over chaos

  • Traffic splitting

    • L7 tag based routing?

  • Traffic steering

    • Look at the contents of a request and route it to a specific set of instances.

  • Ingress and egress routing

Resilency



  • Systematic fault injection

  • Timeouts and Retries with timeout budget

  • Control connection pool size and request load

  • Circuit breakers and Health checks



content-based traffic steering

Missing: application lifecycle management, but not by much

Missing: distributed debugging; provide nascent visibility (topology)

@lcalcote

Connect


Collaborate


Contribute

Join the Community

http://slack.layer5.io

Prereq

Confirm Prerequisites



  1. Start Docker Desktop, Minikube or other.
    (either single-node or multi-node clusters will work)

  2. Verify that you have a functional Docker environment by running :

$ docker run hello-world
Unable to find image 'hello-world:latest' locally
latest: Pulling from library/hello-world
1b930d010525: Pull complete
Digest: sha256:0e11c388b664df8a27a901dce21eb89f11d8292f7fca1b3e3c4321bf7897bffe
Status: Downloaded newer image for hello-world:latest

Hello from Docker!

Docker and Kubernetes

Prereq

@lcalcote

Prepare Docker Desktop

Ensure your Docker Desktop VM has 4GB of memory assigned.

Ensure Kubernetes is enabled.

Prereq

@lcalcote

Deploy Kubernetes

  1. Confirm access to your Kubernetes cluster.

$ kubectl version --short
Client Version: v1.19.2
Server Version: v1.18.8
$ kubectl get nodes
NAME             STATUS   ROLES    AGE   VERSION
docker-desktop   Ready    master   10m   v1.18.8

Prereq

v1.9 or higher

@lcalcote

meshery.io

Deploy Management Plane

Management
Plane

Provides expanded governance, backend system integration, multi-mesh, federation, expanded policy, and dynamic application and mesh configuration.

Control Plane

Data Plane

brew install layer5io/mesheryctl
mesheryctl system start

Prereq

@lcalcote

Using brew

Using bash

curl -L https://git.io/meshery | sudo bash -
mesheryctl system config minikube --token auth.json

Using minikube:

Relating to

Service Meshes

Which is why...

 I have a container orchestrator.

@lcalcote

Core

Capabilities

  • Cluster Management

    • Host Discovery

    • Host Health Monitoring

  • Scheduling

  • Orchestrator Updates and Host Maintenance

  • Service Discovery

  • Networking and Load Balancing

  • Stateful Services

  • Multi-Tenant, Multi-Region

Additional

Key Capabilities

  • Application Health and Performance Monitoring

  • Application Deployments

  • Application Secrets

minimal capabilities required to qualify as a container orchestrator

Service meshes generally rely on these underlying layers.

@lcalcote

Which is why...

 I have an API gateway.

@lcalcote

Microservices API Gateways

north-south vs. east-west

Which is why...


 I have client-side libraries.

Enforcing consistency is challenging.

Foo Container

Flow Control

Foo Pod

Go Library
A v1

Network Stack

Service Discovery

Circuit Breaking

Application / Business Logic

Bar Container

Flow Control

Bar Pod

Go Library
A v2

Network Stack

Service Discovery

Circuit Breaking

Application / Business Logic

Baz Container

Flow Control

Baz Pod

Java Library
B v1

Network Stack

Service Discovery

Circuit Breaking

Application / Business Logic

Retry Budgets

Rate Limiting

@lcalcote

Help with Modernization



  • Can modernize your IT inventory without:

    • Rewriting your applications

    • Adopting microservices, regular services are fine

    • Adopting new frameworks

    • Moving to the cloud

address the long-tail of IT services

Get there for free

Why use a Service Mesh?

  • Bloated service (application) code

  • Duplicating work to make services production-ready

    • Load balancing, auto scaling, rate limiting, traffic routing...

  • Inconsistency across services

    • Retry, tls, failover, deadlines, cancellation, etc., for each language, framework

    • Siloed implementations lead to fragmented, non-uniform policy application and difficult debugging

  • Diffusing responsibility of service management

to avoid...

DEVELOPER

OPERATOR

Decoupling at Layer 5

where Dev, Ops, Product meet

Empowered and independent teams can iterate faster

PRODUCT OWNER

DEVELOPER

OPERATOR

Decoupling at Layer 5

where Dev, Ops, Product meet

Empowered and independent teams can iterate faster

PRODUCT OWNER

layer5.io/landscape

It's meshy out there.

Strengths of Service Mesh Implementations

Different tools for different use cases

a sample

Service mesh abstractions

Meshery is interoperable with these abstractions.

Service Mesh Interface
(SMI)

Multi-Vendor Service Mesh Interoperation (Hamlet)

Service Mesh Performance Specification (SMPS)

A standard interface for service meshes on Kubernetes.

A set of API standards for enabling service mesh federation.

A format for describing and capturing service mesh performance.

to the rescue

  • benchmarking of service mesh performance


  • exchange of performance information from system-to-system / mesh-to-mesh


  • apples-to-apples performance comparisons of service mesh deployments.


  • MeshMark - a universal performance index to gauge a service mesh’s efficiency against deployments in other organizations’ environments



Service Mesh Performance

https://smp-spec.io

Directly provides:

Indirectly facilitates:

  • a vendor neutral specification for capturing details of infrastructure capacity, service mesh configuration, and workload metadata.

Service Mesh Interface (SMI) Conformance

Operate and upgrade with confirmation of SMI compatibility

✔︎ Learn Layer5 sample application used for validating test assertions.


 ✔︎ Defines compliant behavior.

 ✔︎ Produces compatibility matrix.

 ✔︎ Ensures provenance of results.

 ✔︎ Runs a set of conformance tests.

 ✔︎ Built into participating service mesh’s release pipeline.

Q&A

Service Mesh Architectures

Service Mesh Architectures

Data Plane

  • Touches every packet/request in the system.

  • Responsible for service discovery, health checking, routing, load balancing, authentication, authorization, and observability.

Ingress Gateway

Egress Gateway

Service Mesh Architecture

No control plane? Not a service mesh.

Control Plane

  • Provides policy, configuration, and platform integration.

  • Takes a set of isolated stateless sidecar proxies and turns them into a service mesh.

  • Does not touch any packets/requests in the data path.

Data Plane

  • Touches every packet/request in the system.

  • Responsible for service discovery, health checking, routing, load balancing, authentication, authorization, and observability.

Ingress Gateway

Egress Gateway

Service Mesh Architecture

Control Plane

Data Plane

  • Touches every packet/request in the system.

  • Responsible for service discovery, health checking, routing, load balancing, authentication, authorization, and observability.

  • Provides policy, configuration, and platform integration.

  • Takes a set of isolated stateless sidecar proxies and turns them into a service mesh.

  • Does not touch any packets/requests in the data path.

You need a management plane.

Ingress Gateway

Management
Plane

  • Provides backend system integration, expanded policy and governance, continuous delivery integration, workflow, chaos engineering,  configuration and performance management and multi-mesh federation.

Egress Gateway

Service Mesh Architecture

Pilot

Citadel

Mixer

Control Plane

Data Plane

istio-system namespace

policy check

Foo Pod

Proxy Sidecar

Service Foo

tls certs

discovery & config

Foo Container

Bar Pod

Proxy Sidecar

Service Bar

Bar Container

Out-of-band telemetry propagation

telemetry



reports

Control flow

application traffic

Application traffic

application namespace

telemetry reports

Istio Architecture

Galley

Ingress Gateway

Egress Gateway

@lcalcote

Control Plane

Data Plane

octa-system namespace

policy check

Foo Pod

Proxy
Sidecar

Service Foo

discovery & config

Foo Container

Bar Pod

Service Bar

Bar Container

Out-of-band telemetry propagation

telemetry



reports

Control flow

application traffic

Application traffic

application namespace

telemetry reports

Policy
Engine

Security Engine

Visibility
Engine

+

Proxy
Sidecar

+

@lcalcote

Octarine Architecture

Leader

Agent

Control Plane

Data Plane

intentions

Foo Pod

Proxy Sidecar

Service Foo

discovery, config,



tls certs

Foo Container

Bar Pod

Proxy Sidecar

Service Bar

Bar Container

Control flow

application traffic

Application traffic

application namespace

Follower

Consul Client

Consul Servers

Follower

policy



check

Consul Architecture

layer5.io/service-mesh-architectures

WASM Filter

node

@lcalcote

Our service mesh of study: Linkerd

What is Linkerd?

an open platform to connect, manage, and secure microservices

  • Observability

  • Resiliency

  • Traffic Control

  • Security

  • Policy Enforcement

istio.io

github.com/linkerd

@linkerd

@lcalcote

Deploy Linkerd

@lcalcote

  1. Install Linkerd using Meshery



  2. Find control plane namespace



  3. Inspect control plane services



  4. Inspect control plane components

open http://localhost:9081
kubectl get namespaces
kubectl get svc -n linkerd
kubectl get pod -n linkerd

Lab 1

github.com/layer5io/linkerd-service-mesh-workshop

Control Plane

Data Plane

linkerd namespace

Foo Pod

Proxy Sidecar

Service Foo

Foo Container

Bar Pod

Proxy Sidecar

Service Bar

Bar Container

Out-of-band telemetry propagation

telemetry



scarping

Control flow during request processing

application traffic

Application traffic

application namespace

telemetry scraping

Architecture

Prometheus

Grafana

web

CLI

public-api

Linkerd

@layer5

linkerd-controller

sp-validator

Control Plane

destination

tap

web

CLI

proxy-injector

identity

Service Proxy Sidecar

- A Rust-based L4/L7 proxy

- Low memory footprint

- Designed for service mesh use cases

@lcalcote

Capabilities:

  • Transparent, zero-config proxying for HTTP, HTTP/2, and arbitrary TCP protocols.

  • Automatic Prometheus metrics export for HTTP and TCP traffic.

  • Transparent, zero-config WebSocket proxying.

  • Automatic, latency-aware, layer-7 load balancing.

  • Automatic layer-4 load balancing for non-HTTP traffic.

  • Automatic TLS.

  • An on-demand diagnostic tap API.

The proxy supports service discovery via DNS and the destination gRPC API.

the included, non-swappable battery

Data Plane

Pod

Proxy sidecar

App Container

the workhorse

What's Identify for?

@lcalcote

  • Verifiable identity

    • Issues certs

    • Certs distributed to service proxies

    • Mounted as a Kubernetes secret

  • Secure naming / addressing

  • Traffic encryption

security at scale

security by default

Orchestrate Key & Certificate:

  • Generation

  • Deployment

  • Rotation

  • Revocation



linkerd namespace

Prometheus

Grafana

web

CLI

public-api

linkerd-controller

sp-validator

destination

tap

web

CLI

proxy-injector

identity

Q&A

Break

Deploy Sample App

@lcalcote

  1. Multi-language, multi-service application

  2. Automatic vs manual  sidecar injection

  3. Verify install

Use Meshery or install manually

Lab 2

emoji Pod

web Pod

web
Container

emoji-svc Service

web Service

Emojivoto Sample App

@lcalcote

emoji
Container

voting Pod

voting-svc Service

voting
Container

emoji Pod

web Pod

web
Container

emoji-svc Service

web Service

Emojivoto Sample App on the Service Mesh

@lcalcote

emoji
Container

voting Pod

voting-svc Service

voting
Container

Linkerd sidecar

Linkerd sidecar

Linkerd sidecar

Sidecar Injection

@lcalcote

Automatic sidecar injection leverages Kubernetes' Mutating Webhook Admission Controller.



  1. Verify whether your Kubernetes deployment supports these APIs by executing:




  2. Inspect the linkerd-proxy-injector-webhook-config webhook:





If your environment does NOT this API, then you may manually inject the Linkerd proxy.

Lab 2

github.com/layer5io/istio-service-mesh-workshop

kubectl get mutatingwebhookconfigurations
kubectl get mutatingwebhookconfigurations linkerd-proxy-injector-webhook-config -o yaml
kubectl api-versions | grep admissionregistration

Sidecars proxy can be either manually or automatically injected into your pods.

Deploy Sample App with Automatic Sidecar Injection

@lcalcote

  1. Verify presence of the sidecar injector

kubectl get deployment linkerd-proxy-injector -n linkerd

Lab 2

github.com/layer5io/istio-service-mesh-workshop

2.   Confirm namespace annotation

kubectl describe namespace linkerd

sidecar proxy

 Deploy Sample App with Manual Sidecar Injection

@lcalcote

In namespaces without the linkerd.io/inject annotation, you can use linkerd inject to manually inject Linkerd proxies into your application pods before deploying them:

kubectl kustomize kustomize/deployment | \
    linkerd inject - | \
    kubectl apply -f -

Lab 2

github.com/layer5io/istio-service-mesh-workshop

sidecar proxy

Expose Emojivoto via NGINX Ingress Controller

@lcalcote



Inspect the Linkerd proxy of the web pod

NGINX  Ingress

application traffic

Lab 3

github.com/layer5io/istio-service-mesh-workshop

apiVersion: extensions/v1beta1
kind: Ingress
metadata:
  name: web-ingress
  namespace: emojivoto
  annotations:
    kubernetes.io/ingress.class: "nginx"
    nginx.ingress.kubernetes.io/configuration-snippet: |
      proxy_set_header l5d-dst-override $service_name.$namespace.svc.cluster.local:$service_port;
      grpc_set_header l5d-dst-override $service_name.$namespace.svc.cluster.local:$service_port;

spec:
  rules:
    - host: example.com
      http:
        paths:
          - backend:
              serviceName: web-svc
              servicePort: 80

  1. Deploy the NGINX Ingress Controller

2. Configure NGINX Ingress for Emojivoto

Q&A

Telemetry

Service Mesh Interface (SMI)

Service Mesh Performance (SMP)

Configuration

Security

Telemetry

Control Plane

Data
Plane

service mesh ns

Foo Pod

Proxy Sidecar

Service Foo

Foo Container

Bar Pod

Proxy Sidecar

Service Bar

Bar Container

Out-of-band telemetry propagation

Control flow

application

traffic

Application traffic

application namespace

Meshery Architecture

Ingress Gateway

Egress Gateway

Management
Plane

meshery

adapters

gRPC

kube-api

kube-system

generated load

http / gRPC traffic

fortio

wrk2

nighthawk

UI

API

workloads

Meshery WASM Filter

CLI

perf analysis

patterns

@mesheryio

Metrics Dashboard

@lcalcote

Lab 4

  1. Expose Grafana with `linkerd`





    2.

linkerd dashboard &

Grafana

@lcalcote

Lab 6

Distributed Tracing

Jaeger

github.com/layer5io/linkerd-service-mesh-workshop

Distributed Tracing

Jaeger

@lcalcote

The istio-proxy collects and propagates the following headers from the incoming request to any outgoing requests:

  • x-request-id

  • x-b3-traceid

  • x-b3-spanid

  • x-b3-parentspanid

  • x-b3-sampled

  • x-b3-flags

  • x-ot-span-context

Lab 6

kubectl -n istio-system edit svc tracing

github.com/layer5io/linkerd-service-mesh-workshop

Q&A

Break

Request Routing and Canary Testing

@lcalcote

  1. Configure the default route for all services to V1

  2. Content based routing

  3. Canary Testing - Traffic Shifting


layer5.io/workshops

kubectl apply -f samples/bookinfo/networking/destination-rule-all-mtls.yaml

Lab 5

Load Generation

Lab 6

@mesheryio

meshery.io

1. Use Meshery to generate load on sample application

2. View in monitoring tools

Lab 4 Tasks

Fault Injection and Rate-Limiting

@lcalcote

  1. Inject a route rule to create a fault using HTTP delay

  2. Inject a route rule to create a fault using HTTP abort

  3. Verify fault injection

Lab 6

Circuit Breaking

@lcalcote

  1. Deploy a client for the app

    1. With manual sidecar injection:

  2. Initial test calls from client to server

  3. Time to trip the circuit

Lab 7

Lee Calcote

cloud native and its management

@lcalcote

calcotestudios.com/talks

linkedin.com/in/leecalcote

layer5.io/subscribe

@lcalcote

  • Uses pluggable adapters to extend its functionality

    • Adapters run within the Mixer process

  • Adapters are modules that interface to infrastructure backends

    • (logging, metrics, quotas, etc.)

  • Multi-interface adapters are possible

    • (some adapters send logs and metrics)

Mixer Adapters

Layer5

Prometheus

Stackdriver

Open Policy Agent

Grafana

Fluentd

Statsd

®

Pilot

Citadel

Mixer

istio-system namespace

Galley

Control Plane

types: logs, metrics, access control, quota

Metrics

@lcalcote

Mixer

Control Plane

Data Plane

istio-system namespace

Foo Pod

Proxy sidecar

Service Foo

Foo Container

Out-of-band telemetry propagation

Control flow during request processing

application traffic

application traffic

application namespace

telemetry reports

Lab 4

  1. Expose services with NodePort:





  2. Find port assigned to Prometheus:

kubectl -n istio-system edit svc prometheus
kubectl -n istio-system get svc prometheus

Services Observation

Kiali

@lcalcote

Lab 4

  1. Expose services with NodePort:





  2. Find port assigned to Kiali:

kubectl -n istio-system edit svc kiali
kubectl -n istio-system get svc kiali

github.com/layer5io/linkerd-service-mesh-workshop

Timeouts & Retries

@lcalcote

Web

Service Foo

Timeout = 600ms
Retries = 3

Timeout = 300ms
Retries = 3

Timeout = 900ms
Retries = 3

Service Bar

Database

Timeout = 500ms
Retries = 3

Timeout = 300ms
Retries = 3

Timeout = 900ms
Retries = 3

Deadlines

Web

Service Foo

Deadline = 600ms

Deadline = 496ms

Service Bar

Database

Deadline = 428ms

Deadline=180ms

Elapsed=104ms

Elapsed=68ms

Elapsed=248ms

layer5.io/workshops

CCOSS 2020: Taller de contribución a Meshery

By Lee Calcote

Made with Slides.com

CCOSS 2020: Taller de contribución a Meshery

Presented at La Cumbre de Contribuidores de Open Source Software in October 2020.

  • 1,431

More from Lee Calcote

  • O'Reilly Online Live Training - December 2020: Advanced Istio
    Lee Calcote
    1277
  • O'Reilly Online Live Training - December 2020: Introduction to Istio
    Lee Calcote
    1321
  • All Day DevOps 2020: Solving the Service Mesh Adopter's Dilemma
    Lee Calcote
    639
