Making a Smart Kitty Detector
(powered by the cloud Amazon Web Services)

-
@lynnaloo on the internet
-
Makes art, robots, and software
-
Software Engineer @ ETA
-
Really likes cats and turtles
Me.

-
Norfolk.js
-
NodeBots Day Norfolk
-
RevolutionConf
Me.
I organize stuff:


What is Amazon Web Services?
Amazon Web Services (AWS) is a secure cloud services platform, offering compute power, database storage, content delivery and other functionality to help businesses scale and grow.
- Amazon
About AWS
-
It's inexpensive
-
It's reliable(ish)
-
It's secure.
-
It's fast.
-
It's huge [it's Amazon].

AWS Products and Services
-
Cloud Computing
-
File Storage
-
NoSQL & Relational Databases
-
AI & Machine Learning
-
Internet of Things

For the Kitty Detector
-
AWS IoT
-
S3
-
AWS Lambda
-
Amazon Rekognition

Amazon IoT
-
Pub/sub system for hardware*
-
Devices are added as "things"
-
Device messages are filtered by the Rules Engine (SQL).
-
The Rules Engine routes messages to actions.

Amazon IoT
Device to IoT ????
-
IoT supports publish and subscribe via MQTT protocol and publish via HTTPS.
-
For browser-only applications, MQTT messages can be sent and received via web-sockets.
-
IoT has SDKs for Android/iOS, Java, Python, JavaScript (Browser and Node.js), and embedded C.
Can I connect *any* hardware?
-
Nope.
-
It has to be able to support TLS 1.2 for MQTT or SSL certificates for the REST API.
-
-
Sorta.
-
You can tether the hardware to a computer or Raspberry Pi. Or the device can just be a computer running the SDK.
-
There are some proxy hacks for outlying hardware.
-
Amazon AI Services
-
Amazon Lex - Chatbots
-
Amazon Polly - Text to Speech
-
Amazon Rekognition - Images
For developers who want access to AI technologies without having to train or develop their own ML models.
Amazon Rekognition

[
{ Name: 'Animal', Confidence: 98.29473114013672 },
{ Name: 'Cat', Confidence: 97.9908218383789 },
{ Name: 'Adorable', Confidence: 97.9908218383789 },
{ Name: 'Plant', Confidence: 78.9802474975586 },
{ Name: 'Potted Plant', Confidence: 64.9802474975586 },
{ Name: 'Mammal', Confidence: 64.9908218383789 },
{ Name: 'Manx', Confidence: 64.9908218383789 },
{ Name: 'Pet', Confidence: 64.9908218383789 }
]
AWS Lambda
-
Part of the "serverless" architecture
-
Users run code without provisioning or managing servers
-
You're only charged when your code is executed
-
Supports several languages
-
Functions are executed by events

AWS Lambda


AWS Lambda
'use strict';
const fetch = require('node-fetch');
const AWS = require('aws-sdk');
const s3 = new AWS.S3();
module.exports.save = (event, context, callback) => {
fetch(event.image_url)
.then(response => response.buffer())
.then(buffer => (
s3.putObject({
Bucket: process.env.BUCKET,
Key: event.key,
Body: buffer,
}).promise()
))
.then(() => {
callback(null, 'Saved');
})
.catch((error) => {
callback(error, null);
});
};
Back to the Project:
A motion detector that texts a user when a cat (and only a cat) is detected.

Kitty Detector Parts List
-
Raspberry Pi 3
-
PIR Sensor
-
External Power Source
-
Lead Wires
-
Detector case (optional)
-
1 moving kitty (optional)
The Code
-
Raspberry Pi Hardware/Amazon IoT Code: https://github.com/lynnaloo/kitty-detector
-
Serverless Framework/Lambdas: https://github.com/lynnaloo/go-away-kitty

Demo Time!

Making a Smart Kitty Detector Powered by Amazon Web Services
By Linda Nichols
Making a Smart Kitty Detector Powered by Amazon Web Services
This talk includes a quick overview of Amazon Web Services and how they can be used to power a "Smart" kitty detector.
