Less is more:

a proposal to enhance collaboration

MXCuBE meeting @ Diamond Light Source, 1 February 2018

Minimalistic presentation by M. Guijarro

Collaboration from a developer perspective

People working altogether

Lots of interaction !

Technical debates

Shared knowledge

Everybody on the same boat

Integration of newcomers

Better quality software

MXCuBE collaboration

What do we share ? (from the MOU)

  • 2 graphical frontends
  • Beamline control abstraction layer

3 developers are pushing the vast majority of commits

New developers have difficulties to participate

Challenges ahead: test suite, Python 3, modernizing software architecture

Impediments to developers collaboration

  • Code organization
  • Lack of documentation
  • Code complexity
  • No tests suite

Code Organization

User Interface

Web

Qt

Hardware Abstraction

2.2

master

  • Git repositories with branches & submodules

MXCuBE 3

MXCuBE 2 dev.

MXCuBE 2.2

Hard to see the big picture, hard to make pull requests, hard to keep coherency

Code Organization: Hardware Abstraction

  • Abstract Hardware Objects -- 10
  • Mockup Hardware Objects -- 31
  • Site-specific Hardware Objects
    • 48 (ESRF)
    • 23 (EMBL-HH)
    • 14 (MAXIV)
    • 70 (SOLEIL)

Missing abstract classes

80% of the code is specific, impossible to test

Code complexity

  • Loosely tied components
    • subscription and events emitting
  • Many inheritance levels
  • Long callback chains
  • Beamline control code

Hard to get into the code, hard to debug

No automatic testing: regression steps in !

MXCuBE collaboration entry price is too high

MXCuBE maintenance cost is high too

Is MXCuBE architecture adapted to current needs?

Digression:

something to tell about MXCuBE 3 development

  • Queue
@mxcube.route("/mxcube/api/v0.1/queue/start", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue/stop", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue/abort", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue/pause", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue/unpause", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue/clear", methods=['PUT', 'GET'])
@mxcube.route("/mxcube/api/v0.1/queue", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue_state", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue/<sid>/<tindex>/execute", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/queue/<sqid>/<tqid>", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/queue/delete", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/queue/set_enabled", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/queue/<sid>/<ti1>/<ti2>/swap", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/queue/<sid>/<ti1>/<ti2>/move", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/queue/sample-order", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/queue/<sample_id>", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue/<node_id>/toggle", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/queue/dc", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue/char_acq", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue/char", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue/mesh", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue/<id>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue/<sample_id>/<int:method_id>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/queue/json", methods=["GET"])
@mxcube.route("/mxcube/api/v0.1/queue/automount", methods=["POST"])
@mxcube.route("/mxcube/api/v0.1/queue/num_snapshots", methods=["PUT"])
@mxcube.route("/mxcube/api/v0.1/queue/group_folder", methods=["POST"])
@mxcube.route("/mxcube/api/v0.1/queue/group_folder", methods=["GET"])
@mxcube.route("/mxcube/api/v0.1/queue/auto_add_diffplan", methods=["POST"])

MXCuBE 3 control API

  • Data collection
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections/<colid>/mode", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections/<colid>", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections/<colid>", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections/<colid>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections/<colid>", methods=['DELETE'])
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections/status", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/samples/<id>/collections/<colid>/status", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/samples/<sampleid>/collections/<colid>/run", methods=['POST'])
  • Access to beamline setup
@mxcube.route("/mxcube/api/v0.1/beamline", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/beamline/<name>/abort", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/beamline/<name>/run", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/beamline/<name>", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/beamline/<name>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/beam/info", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/beamline/datapath", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/beamline/prepare_beamline", methods=['PUT'])

MXCuBE 3 control API

  • Sample changer
@mxcube.route("/mxcube/api/v0.1/sample_changer/samples_list", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/state", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/loaded_sample", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/contents", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/select/<loc>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/scan/<loc>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/mount/<loc>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/unmount/<loc>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/unmount_current/", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/mount", methods=["POST"])
@mxcube.route("/mxcube/api/v0.1/sample_changer/unmount", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/get_maintenance_cmds", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/get_global_state", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/get_initial_state", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sample_changer/send_command/<cmdparts>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/login", methods=["POST"])
@mxcube.route("/mxcube/api/v0.1/signout")
@mxcube.route("/mxcube/api/v0.1/login_info", methods=["GET"])
@mxcube.route("/mxcube/api/v0.1/login/request_control", methods=["POST"])
@mxcube.route("/mxcube/api/v0.1/login/observers", methods=["GET"])
@mxcube.route("/mxcube/api/v0.1/login/request_control_response", methods=["POST"])
  • Login

MXCuBE 3 control API

MXCuBE 3 control API

  • Sample centring, sample view handling
@mxcube.route("/mxcube/api/v0.1/sampleview/camera/subscribe", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sampleview/camera/unsubscribe", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/camera/save", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/camera", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sampleview/camera", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/<point_id>/moveto", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/shapes", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sampleview/shapes/<sid>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sampleview/shape_mock_result/<sid>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sampleview/shapes", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/sampleview/shapes/<sid>", methods=['DELETE'])
@mxcube.route("/mxcube/api/v0.1/sampleview/zoom", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/backlighton", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/backlightoff", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/frontlighton", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/frontlightoff", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/<motid>/<newpos>", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/<elem_id>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/startauto", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/start3click", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/abort", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/click", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/accept", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/reject", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/movetobeam", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/sampleview/centring/centring_method", methods=['PUT'])
  • Diffractometer
@mxcube.route("/mxcube/api/v0.1/diffractometer/phase", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/diffractometer/phaselist", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/diffractometer/phase", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/diffractometer/platemode", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/diffractometer/movables/state", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/diffractometer/aperture", methods=['PUT'])
@mxcube.route("/mxcube/api/v0.1/diffractometer/aperture", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/diffractometer/info", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/lims/samples/<proposal_id>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/lims/dc/thumbnail/<image_id>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/lims/dc/<dc_id>", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/lims/proposal", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/lims/proposal", methods=['GET'])
  • LIMS (ISPyB) integration
@mxcube.route("/mxcube/api/v0.1/workflow", methods=['GET'])
@mxcube.route("/mxcube/api/v0.1/workflow", methods=['POST'])
@mxcube.route("/mxcube/api/v0.1/workflow/dialog/<wf>", methods=['GET'])
  • External experiment control (workflows, need extra server)

MXCuBE 3 control API

Only 120 API functions are needed to have all features of MXCuBE

For completeness: 21 signals have to be emitted too

# diffractometer
socketio.emit('diff_phase_changed', data, namespace='/hwr')

# sample changer
socketio.emit('sc', msg, namespace='/hwr')
socketio.emit('sc_state', state_str, namespace='/hwr')
socketio.emit("loaded_sample_changed", {'address': address, 'barcode': barcode}, namespace="/hwr")
socketio.emit("set_current_sample", sample , namespace="/hwr")
socketio.emit("sc_contents_update")
socketio.emit("sc_maintenance_update", {'state': json.dumps(state_list), 'commands_state': json.dumps(cmd_state), 'message': message}, namespace="/hwr")

# sample centring
socketio.emit('sample_centring', msg, namespace='/hwr')
socketio.emit('update_shapes', {'shapes': shape_dict}, namespace='/hwr')
socketio.emit('update_pixels_per_mm', {"pixelsPerMm": ppm}, namespace='/hwr')
socketio.emit('beam_changed', {'data': ret}, namespace='/hwr')

# results and plotting
socketio.emit('grid_result_available', {'shape': shape}, namespace='/hwr')
socketio.emit('energy_scan_result', {'pk': pk, 'ip': ip, 'rm': rm}, namespace='/hwr')
socketio.emit("new_plot", plot_info, namespace="/hwr")
socketio.emit("plot_data", data, namespace="/hwr")
socketio.emit("plot_end", data, namespace="/hwr")

# beamline setup
socketio.emit('motor_position', movable, namespace='/hwr')
socketio.emit('motor_state', movable, namespace='/hwr')
socketio.emit("beamline_action", msg, namespace="/hwr")
socketio.emit("beamline_value_change", data, namespace="/hwr")
socketio.emit("mach_info_changed", values, namespace="/hwr")

Identification of MXCuBE base building blocks

Login

LIMS

Beamline setup

Sample Changer

Sample centring

Diffractometer

Queue

Data collection

External exp. control

A proposal to enhance collaboration

Let's upgrade the Abstraction idea



Let's facilitate test/simulation

Current architecture

Qt UI

web UI

Hardware Objects

web backend

Hardware Objects

low-level beamline control

Moving to a higher-level abstraction

  • New architecture proposal inspired by work on MXCuBE 3

Qt UI

web UI

beamline control API

specific beamline control

Conclusion

Less is more

  • What about removing beamline-specific code from MXCuBE repository ?
    • makes it more clear what is really shared of MXCuBE
  • Beamline control layer inspired by MXCuBE 3 as a "contract" between UI and underlying hardware control
    • only 120 functions

Much cleaner API for User Interfaces

Good use case for semantic version numbers

API documentation would be straightforward to write

Complete simulation environment is possible

Continuous Integration objective could be achieved

Open Questions

  • Do we want to enhance collaboration by simplifying our code base ?
  • Do we want to revamp MXCuBE beamline abstraction layer ?
  • Do we accept to limit MXCuBE  scope to the user interface and new beamline control API to make the project more coherent ?
  • How long are we going to keep MXCuBE 2 ?
  • What about adopting the same beamline control API for both versions ?
  • Should we add external control of MXCuBE within the deliverables of our collaboration ? (for the new MOU)

About the speaker...

  • Since this autumn the time I can dedicate to MXCuBE development has been drastically reduced
  • New duties at ESRF: team leader of the BLISS project

This is not good-bye BUT...

please Steering Committee make sure MXCuBE has enough developers !

mxcubemeeting_dls_lessismore

By Matias Guijarro

mxcubemeeting_dls_lessismore

A proposal to enhance collaboration

  • 491
Loading comments...

More from Matias Guijarro
