Handling SVGs

From      pponent  to  c     mponent

console.log(Maya)

Senior Frontend Developer at Cloudinary

Core Maintainer of StorefrontUI

Organizer of Vuejs Israel

Nuxt.js Ambassador

Blogger

Bookworm

What is SVG?

Scalable
Vector
Graphics

<ellipse rx="150" ry="150" cx="150" cy="150" fill="rgb(241, 194, 50)" />
<svg>
  <path fill="#8899A6" d="M6 10l3 23c0 1.657 4.029 3 9 3s9-1.343 9-3l3-23H6z"></path>
  <path fill="#D3A471" d="M7 10l3 22.644c0 1.243 3.582 2.25 8 2.25s8-1.007 8-2.25L29 10H7z"></path>
  <path fill="#CCD6DD" d="M27.756 19.538L29 10H7l1.244 9.538z"></path>
  <path fill="#E1E8ED" d="M25.982 19.538L27 10H9l1.018 9.538z"></path>
  <ellipse fill="#ECD2A7" cx="18" cy="19.455" rx="9.764" ry="2.355"></ellipse>
  <path fill="#AA8DD8" d="M21.836 19.144l1.627-18.067l-2.988-.27l-1.651 18.337z"></path>
  <path fill="#55ACEE" d="M5.696 10.003c-.179 1.05-.162 2.363.413 2.527c.46.132 1.104-.09
                          1.639.177c.535.267.963.965 1.506 1.151c1.04.356 1.678-.299
                          2.303-.221c1.188.148 1.721 1.284 2.702 1.373c.98.089 1.781-.738
                          2.701-.709c.984.032.936.767 2.48.797c1.516.029 1.766-.959
                          2.657-1.019c.891-.059 1.471.547 2.303.399c.832-.149 1.177-1.017
                          1.86-1.196c.683-.178 1.045.326 1.639.177c.594-.148.907-1.17
                          1.264-1.438c.356-.267 1.571 1.26 1.277-1.663c-.536-5.328-19.
                          13-.563-20.882-.681c-1.753-.119-3.491-1.845-3.862.326z" />
  <ellipse fill="#88C9F9" cx="18" cy="10.011" rx="12.35" ry="3.8"></ellipse>
  <path fill="#9266CC" d="M23.463 1.077L20.475.808l-.853 9.474c-.001.007-.006.013-.006.019c0
                          .276.672.5 1.5.5s1.5-.224 1.5-.5V10.3h.017l.83-9.223z"/>
  <path fill="#553788" d="M23.463 1.077c-.025.275-.714.438-1.539.363c-.825-.074-1.474-
                          .358-1.449-.633c.025-.275.714-.438 1.539-.363s1.474.358 1.449.633z" />
  <ellipse fill="#AA8DD8" cx="20.314" cy="19.19" rx="1.5" ry=".5"></ellipse>
  <g fill="#292F33">
    <!=...=>
  </g>
 </svg>

SVG

GIF, PNG, JPG, etc.

Paths (Vectors)

Shapes

Text elements

Fixed dimension

BUT...

BUT...

We are still not comfortable in using SVGs

#1 "BUT"

We can use HTML & CSS to build graphics

#2 "BUT"

No single standard that matches all

const webpack = require('webpack');

module.exports = {
  entry: './src/index.js',
  module: {
    rules: [
      {
        test: /\.(js|jsx)$/,
        exclude: /node_modules/,
        use: ['babel-loader'],
      },
      {
        test: /\.svg$/,
        use: [
          {
            loader: 'svg-url-loader',
            options: {
              limit: 10000,
            },
          },
        ],
      },
    ],
  },
  ...
};
<template>
  <nav>
    <a href="https://github.com/webpack/webpack"
       arial-label="Webpack">
      <WebpackLogo />
    </a>
  </nav>
</template>
<script>
import WebpackLogo from './static/webpack.svg';

export default {
  name: 'SVG Example',
  components: {
    WebpackLogo,
  },
};
</script>
import WebpackLogo from './static/webpack.svg';

const () => (
 <WebpackLogo width={50} height={50}/>
)
<body>
  <svg style="display: none">
    <symbol viewBox="0 0 32 32" id="heart-icon">
    </symbol>
  </svg>
  <svg width="24px" height="24px">
    <use xlink:href="#heart-icon"></use>
  </svg>
</body>

SVG Sprites

with <symbol> and <use>
export const mail = {
  path: [
    `M11.8125 9.8125H2.1875C1.46289 9.8125 0.875 9.22461 0.875 8.5V1.5C0.875
    0.775388 1.46289 0.1875 2.1875 0.1875H11.8125C12.5371 0.1875 13.125
    0.775388 13.125 1.5V8.5C13.125 9.22461 12.5371 9.8125 11.8125 9.8125ZM2.1875
    1.0625C1.94578 1.0625 1.75 1.25828 1.75 1.5V8.5C1.75 8.61594 1.79594 8.7275
    1.87797 8.80953C1.96 8.89156 2.07156 8.93749 2.18749 8.93749H11.8125C11.9284
    8.93749 12.04 8.89156 12.122 8.80953C12.2041 8.72749 12.25 8.61593 12.25
    8.5V1.5C12.25 1.38406 12.2041 1.2725 12.122 1.19047C12.04 1.10844 11.9284
    1.06251 11.8125 1.06251L2.1875 1.0625Z`,
    `M7.00088 5.21008C6.71158 5.21063 6.42995 5.11492 6.20025 4.93883L1.33959
    1.19817C1.14763 1.05051 1.111 0.775439 1.25865 0.583485C1.40631 0.391531
    1.68138 0.354893 1.87334 0.502549L6.734 4.24321C6.8915 4.36407 7.11025
    4.36407 7.26775 4.24321L12.1284 0.502549C12.3204 0.354891 12.5954 0.391533
    12.7431 0.583485C12.8907 0.775438 12.8541 1.05051 12.6622 1.19817L7.80149
    4.93883C7.57181 5.11492 7.29017 5.21062 7.00086 5.21008H7.00088Z`
  ],
  viewBox: '0 0 24 24'
}

JSX Component


<icon path={mail.path} viewBox={mail.viewBox} />
export const icon = ({ viewBox, path, size }) => (
  <svg
    viewBox={viewBox}
    width={size}
    height={size}
    style="fill: currentColor;"
  >
    { path.forEach(d => (
      <path d={d} />
    )}
  </svg>
)

SVG is too powerful and awesome to miss out 😉

Cool Text Effects & Animations

Animations & Interactive

Boom - Sarah Drasner

Animations & Interactive

Animations & Interactive

Loaders & Animations

Scalable Logos & Icons

Micro-interactions & UI Elements

3D Graphics

The benefits

Scalability

Editable & scriptable

Animate-able (CSS and/or JS)

Accessible

Smaller in size

Interactively

Readable

Less CSS-depending for colors

Semantically correct (image)

Ease of use

And anything you can think of

Probably after you read this book 👉

How to create SVG?

console.log(takeaways)

What scenarios?

Choose the most comfortable implementation for SVG usage

Logo & Icons - Think SVG first

Take a course with Sarah Drasner 😝

THANK YOU
