/(Every|some)thing you wanted to know about RegEx/

This talk will:

Start very theoretical

End very practical

Hopefully something for everyone

clear up a term

"Regular Expression"

"Regex"

"Regexp"

What is "language"?

"language" is the ability to use and acquire systems of communication

"a language" is an implementation of one of those systems

Grammar

Rules for the structure of the language, and how that translates to MEANING

Syntax

Rules for more nuanced differentiation in meaning:

active vs passive

declarative vs imperative

Grammar is the difference between "Dog bites man" and "Man bites dog."

subject verb object

I have.

Rule: Independent Clauses contain a Subject, verb

IC = S, V

I have the high ground.

, and optional object

, O*

A combination of symbols that represents a grammar rule is an

expression

IC = SVO*

Note: a regular language is a language that has a well defined and strict grammar

Many spoken languages are not regular, because humans.

So an expression that defines the grammar of a regular language is a

Regular Expression

Pivot

What is a grammar, in the context of a programming language?

programming languages as Languages

Sets of rules (grammars) which defined what keywords, expressions, characters can appear in what order, and what the meaning is of those things.

For example:

An expression is anything that can be on the right of an equals sign.

const a = b + 3

expression

Recursive Definition

Exp =:: Exp

Exp =:: Exp + Exp

Exp =:: Exp - Exp

Exp =:: (Exp)

Exp =:: Exp && Exp

Exp =:: Exp || Exp

Exp =:: ! Exp

State Machines

Any computer program can be modeled as a "state machine", shown as a graph with edges and nodes

Input to a state machine moves the current state from Start to End

State Machines === Regular Expressions

ab

a*

a|b

state machines

validate input

"abc"

"abc...c"

"ab"

End

Takeaway

A regular expression is a definition of a language grammar

State machines validate input for a regular expressions

Valid input == part of a language

Pivot

Epiphany: Hey, we can use this for pattern matching!

When you define a regular expression for a string, you are (behind the scenes) defining a grammar for a new language that the string is a part of

is a regular expression for the grammar of a language in which "Hello There!" is the only valid entry

anatomy of regular expressions

/Hello There!/gi

Pattern:

a set of characters which describe possible matches (or rather, described the grammar of a language which words may or may not be a part of)

Flags:

describe the way that the pattern should be applied to possible matches

global

ignore case

multi-line

/Hello There!/

Characters:

character literals on which to match

Metacharacters:

provide instructions on how to interpret characters

metacharacters

"no"

/no/

"nooo"

/nooo/

"nooo"

/no{3}/

"no...o"

/no{3,10}/

"no..."

/no{3,}/

"no..."

/no{1,}/

"n..."

/no*/

quantifier

any

"n..."

/na{0,}/

"no..."

/no+/

one or more

metacharacters

"abc"

/abc/

"abc"

/[abc]*/

"abcd"

/[a-d]*/

"abYZ"

/[a-zA-Z]*/

"aB123"

/[a-zA-Z0-9]*/

"aB123"

/\w*/

set

word character

set and range

"a3ç∂eƒ"

/[a-zA-Z0-0\W\s]*/

"a3ç∂eƒ"

/.*/

any character

metacharacters

quantifiers

{n,n}

* any of

+ one or more

? zero or one

sets, ranges

[n-n]

\w alphanumeric

\d digit

\W symbol

grouping

(nn)

(nn) capture

(?=nn) non-capture

^ start of word

$ end of word

| or

how regular expressions are applied strings

consider

"Dexter Jettster"

"Dexter"

Greediness

Regular expressions by default will match the longest string possible

consider

"<p>TO͇̹̺ͅƝ̴ȳ̳ TH̘Ë͖́̉ ͠P̯͍̭O̚N̐Y̡</p>"

match as few characters as possible

"<p>TO͇̹̺ͅƝ̴ȳ̳ TH̘Ë͖́̉ ͠P̯͍̭O̚N̐Y̡</p>"

Laziness

Let's build one

currency

Should validate these:

$1

$1.00

$1,000

$1,000,000.00

And invalidate these

$1,

$1,00

$11,00

Version: 1

- A currency symbol

- One or more digits

- Zero or one:

- period followed by 2 digits

$1.00

$1,000

$1,000.00

Let's step back and plan this out

$0.10

$1

$1.10

$1,000

$1,000.00

$100,000,000

$0               .10

$1

$1               .10

$1    ,000

$1    ,000       .00

$111  ,000,000

$1,

$1,00

1.00

$11,00

$01,000

$00,000

$1    ,

$1    ,00

 1               .00

$11   ,00

$01   ,000

$000  ,000

Currency Symbol

1-3 digits

(no leading 0 unless it is the only character)

0 or more groups of a comma and 3 digits

0 or 1 of a period and 2 digits

Currency Symbol

1-3 digits (no leading zeros)

0 or more: groups of a comma and 3 digits

0 or 1 of: a period and 1 or 2 digits

\$(0|[1-9][0-9]{0,2})

(,\d{3})*

(\.\d{1,2})?

Version: 2

- implement 3 rules

- add start and end characters

$1.00

$1,000

$1,000.00

$1,

$1,00

$01.00

$00,000.00

Let's build one

Date:

MM/DD/YYYY

M/D/YYYY

Version: 1

1 or 2 digits

a slash

1 or 2 digits

a slash

4 digits

allows:

1/1/2018

11/12/2018

99/99/9999

Version: 2

A group of

- "0" and a single 1-9 digit

- OR a "1" and single 0-2 digit

A slash

A group of

- an optional "0" and a single 1-9 digit

- OR "12"

A slash

4 digits

allows:

1/1/2018

11/12/2018

Fails:

99/99/2018

11/12/0000

211/12/20189

Version: 3

Start of word

A group of

- "0" and a single 1-9 digit

- OR a "1" and single 0-2 digit

A slash

A group of

- an optional "0" and a single 1-9 digit

- OR "12"

A slash

"19" or "20 and any 2 digits

End of word

allows:

1/1/2018

11/12/2018

Fails:

99/99/2018

11/12/0000

211/12/20189

Leap year!

But wait...

^(((0[1-9]|[12][0-9]|3[01])[- /.](0[13578]|1[02])|(0[1-9]|[12][0-9]|30)[- /.](0[469]|11)|(0[1-9]|1\d|2[0-8])[- /.]02)[- /.]\d{4}|29[- /.]02[- /.](\d{2}(0[48]|[2468][048]|[13579][26])|([02468][048]|[1359][26])00))$

Let's build one

email address

A word character, hyphen, underscore, or period

an @ symbol

1 or more word characters

a period

between 2 to 5 word characters

international TLD

like .co.uk

an ip address instead of a domain

spaces inside quotation marks

comments inside parenthesis (WHAT?)

international characters or 😀.com

Uhhh...

rfc822 email address

or

/.+@.+/

then send a confirmation link

Recap

Language and Grammar
Expressions == state machines == languages
Building blocks of Regular Expressions
Lazy vs Greedy
Creating a regex, planning
Nail & Hammer problems

/b?eg?i?n?ni?n?g?d?/

"end"

"beginning"

Thank you!

References

usd currency parsing https://regexr.com/3ivk1

metacharacters https://help.relativity.com/9.0/Content/Relativity/Regular_expressions/Regular_expression_metacharacters.htm

RFC Email spec http://www.ex-parrot.com/~pdw/Mail-RFC822-Address.html

regular languages https://nikic.github.io/2012/06/15/The-true-power-of-regular-expressions.html

lea verou regex talk https://www.youtube.com/watch?v=EkluES9Rvak

greedy vs lazy https://www.regular-expressions.info/repeat.html

parsing regular expressions http://matt.might.net/articles/parsing-regex-with-recursive-descent/
