Implementing CQRS with Akka

Michał Tomański

@michaltomanski

CQRS

What is this about?

• Command Query Responsibility Segregation
• Design/architecture pattern

class UserService {
    public void createUser(User user);
    public User getUser(long id);
}

And that's basically it

Let's mix it!

Event Sourcing

• The state of an object is equivalent to all the past events applied one by one
• Persisting all the event
• Events are immutable, they are facts
• Events can be replayed to restore the state

DDD

• Domain-Driven Design
• Software development approach
• Domain first
• Can be used with many other things

Event Sourcing

• System receives command
• Command gets validated
• Command generates events
• Events get persisted
• Events are applied on the state

With DDD

Why?

• Persist facts
• Write only, never modify/delete
• Better domain modelling
• The state can be recovered
• No logic evolution problem
• Temporal queries
• Free audit logs / BI data

Event Sourcing

Challenges

• Change of mindset in data modelling
• Too many events to reply => snapshotting
• Events evolution, supporting old events
• Long startup time (events are being replayed) => do we need all the entities at the startup?
• High memory usage => sharding and passivation

- Cool, but how do we query this thing?

- Well, you don't

Why bother?

• Everything said earlier
• Suitable database engines for each side
• Independent read and write side scalability
• Independent data replication factor
• Read or write oriented domain
• Better performance with prepared views
• Loose coupling

Let's build something!

Awesome Timer

®

• Measures the time
• Online
• Users see other users' results (rivalry)

Overview

Awesome Timer

®

Write side

• Accept user's new time
• Remove the user's time (in case of unintentionally stopping the timer)
• Add +2s (penalty)

Awesome Timer

®

Read side

Awesome Timer

®

Writes and reads

• Extremely simple write side (just persist the username and the time), but with (hopefully) a lot of traffic
• Quite complicated and expensive reads (calculating best average of 100 among thousands of entries, querying multiple users)
• Typical CRUD is not the case here

Give me the code!

- But wait, Scala? Isn't it ugly?

- But wait, Scala? Isn't it ugly?

- Doesn't have to be

lazy val fib: Stream[Int] = 0 #:: 1 #:: fib.zip(fib.tail).map { case (a, b) => a + b }
fib drop 5 take 10 toList
// List(5, 8, 13, 21, 34, 55, 89, 144, 233, 377)

workers.foreach(_ ! PoisonPill)

case class Person(name: String, age: Int)
val somebody = Person("Michal", 25)
somebody match {
  case Person(name, 25) => s"$name is 25 years old"
  case Person(name, ) => s"$name is not 25 years old"
}

- Ok, how do we do that? We build all of those persistence, projections etc?

- Let me introduce you Akka.

• A toolkit focused on actors model
• Useful for concurrent, distributed and message driven systems
• High-level abstraction
• For Scala and Java

Actor

• Encapsulate state and behavior
• React to a message
• Location transparency
• Supervision

Actor

class CounterActor extends Actor {
  var counter = 0

  def receive = {
    case IncreaseCounter(amount: Int) => counter = counter + amount
    case GimmeCounter => sender ! counter
    case _ => println("Unknown message")
  }
}

actor ! IncreaseCounter(5) // tell

actor ? GimmeCounter // ask

Persistent Actor

• Persist every valid event to the journal
• Do your business logic after persistence
• Replay all the events when needed
• To make the recovery faster, use snapshots

Persistent Actor

class PersistedCounter extends PersistentActor {
  var counter = 0

  override def receiveCommand: Receive = {
    case increase: IncreaseCounter =>
      persist(increase) { event =>
        counter = counter + increase.amount
      }
    case GimmeCounter => sender ! counter
  }

  override def receiveRecover: Receive = {
    case increase: IncreaseCounter => counter = counter + increase.amount
    case RecoveryCompleted => println("Events recovery completed")
  }

  override def persistenceId: String = "persisted-counter"
}

Persistent Actor

As a domain entity

Cluster sharding

As a domain entities sharding

Projection

Akka Persistence Query as a projection

Controllers

Communicating with the world

Eventual consistency

Should I care?

• Read data will be consistent with what is inside the event store... eventually.
• Getting an updated view by the user might take a while
• But isn't it always the case?
• Data is not wrong, it's just old

Eventual consistency

Should I care?

• Well, there might be a problem while making domain validations against views...
• When? When not?
• Send a compensation event
• Tweak with polling times
• Keep track of inconsistency issues
• ... Or do not design your (micro)service this way

Cubing time

Live demo

Summary

We have a service...

• That can have read and write model scaled independently
• With databases suitable for read and write
• Easy to integrate with other services via events messaging
• Easy to be scaled horizontally with state recovered
• With complete and immutable events history
• With prepared expensive views
• Easy to be tested and debugged (just dump events from prod)
• Written using DDD

• In Scala (•‿•)

Implementing CQRS with Akka

Michał Tomański

@michaltomanski

slides.com/michaltomanski/cqrs

github.com/michaltomanski/cqrs-demo
