Q4-Nathan

Site Visits

Goal:

• review current process
• gather information from existing users
  •  product position
  • needs
  • wants

5 Doctors

• Talk about app
• QA pain app
• align bio mechanics philosophies
  • arch or post
  • exam procedure

Done by: Nov 14

• Find order trends
• What's missing
• What's wrong

Validation

Product Features

Features 2.0

-Arch Width

- Heel width from raw data

  - Fifth ray and 1st ray re-design

    - 3/4 length angle + smooth drop

    - Half length Sols

    - Met Pad positioning

    - Heel spur hole

    - Sports sols

Arch Width

Arch width needs to start being limited like ball widths.

Currently:
heel width<arch width< ball width

Plan:

Contour cut to match shoe last. ∴ arch width<heel width<ball width

Heel Width

Heel width needs to start being measured.

Currently:

limited by heel width averages

Plan:

Needs to be a check with deviations that give healthy range to be measured

Ray Dropout shape

Current: rectangular shape with ratio defined widths/lengths

Goals:

• verify locations as accurate
• change shape to more designed anatomical shape

Length Cut

Current: Cut is 3/4 at toe length straight.

Goals:

• All cuts should be at T-line angle
• T-line cut introduced
• Tapered edge (in CAD?) (in production?)

Met Pad

Current: experimental Tline offset

Goals:

• Verify  current method
• develop in app Experience

Heel Spur

Current: Does not exist

Goal: explore heel spur size and location to implement. should sync with main hole of Bottom of SOLS.

• Product Specification
• Product in-house validation

White papers

White Papers

• Features
• Diseases

Photo Box Study

• Sub-talar misalignment
• Arch photo

1. 2 Days

2. 2 Days
3. 2 Days

4. 3 days

5. 2 days
6. 3 days

7. 2 days

1. In house photo box/ study prep
2. photograph 24 feet
3. photograph 24 feet with SOLS
4. Picture analysis (back of foot)
5. White paper
6. Picture analysis (arch of foot)
7. White paper

PedCat/IRB

• make SOLS from 3d surfaces
• analyze IRB findings

Set up relationship with WC Docs

• get scans with app
• get scans with Ped Cat
• Procedure to compare
• Marry to IRB findings.
