Accessbility testing for developers
Alexander Vassbotn Røyne-Helgesen
Manager, Front-end Developer @ Bekk
A website is not necessarily universally designed, even though it is in line with the current requirements and guidelines
Meaningfull html
Enable the keyboard
Handle focus
Coverage with tests
Meaningfull HTML
<label for="roundTrip">
Round Trip
</label>
<input type="radio" id="roundTrip">Intro to ARIA
Role: What is it?
<span role="button" onClick={} onKeypress={} tabIndex={}></span>State: What state is it in?
<button aria-checked="false"></button>Property: What's the nature of it?
aria-haspopup="true"
aria-label="Close modal"
People with and without disabilities
Disability simulation
Manual
Automatic
One cannot test all WCAG criteria automatically. In fact, very few of them can be tested automatically, without even evaluating them manually. I believe that at best, only four of the 35 criteria apply according to Norwegian law, which can be fully tested automatically:
4.1.1 Parsing must be possible. In other words, the HTML must be valid and according to specification
1.4.3 Contrast between text and background should be good enough
2.1.1 All functionality is available via keyboard
3.1.1 Page language must be specified (lang attribute)
Automated testing
Directive-specific unit tests
Text alt. / Labelling
Keyboard operability
ARIA attribute matching
Labeling unit test
it('should apply aria-hidden="true" when parent has valid label', inject(function() {
const el = make(
`<md-radio-button
aria-label="Squishy Avatar"
role="radio" tabindex="0"
>
<div class="md-container"></div>
<div class="md-label">
<md-icon md-svg-icon="android"></md-icon>
</div>
</md-radio-button>
`
);
expect(el.find("md-icon").attr("aria-hidden")).toEqual("true");
}));
Keyboard unit test
it("closes on escape", inject((document, CONSTANTS) => {
const menu = setup();
openMenu(menu);
expect(getOpenMenuContainer(menu).length).toBe(1);
const openMenuEl = document.querySelector("md-menu-content");
pressKey(openMenuEl, CONSTANTS.KEY_CODE.ESCAPE);
waitForMenuClose();
expect(getOpenMenuContainer(menu).length).toBe(0);
}));
Integration / End to end tests
Color contrast
Widget keyboard interop
Document-level rules
Get help with an API
Label / name computation
Incorrect aria usage
Color contrast
Data table markup
Viewport and zooming issues
$ npm i axe-core --save-devRuns locally
Open source
Free
Integration tests
Unit tests
Example
/*eslint-env node, mocha */
import React from "react";
import chai, { expect } from "chai";
import chaiEnzyme from "chai-enzyme";
import Cover from "components/details/Cover";
import axe from "axe-core";
import { mountToDoc, check } from "../../../../../test/helpers";
chai.use(chaiEnzyme());
const props = {};
describe("<Cover />", () => {
it("has no aXe violations", done => {
const component = mountToDoc(<Cover {...props} />);
const linkNode = component.getDOMNode();
axe.run(linkNode, (err, { violations }) => {
if (err) done(err);
expect(err).to.equal(null);
check(done, () => {
expect(
violations.length,
violations
.map(
({ help, helpUrl, description }) =>
`${help}: ${description}. Please check => ${helpUrl}`
)
.join("")
).to.equal(0);
});
});
}).timeout(5000);
});
End to end keyboard test
/*----- menu.e2e.ts -------*/
import { MenuPage } from './menu-page';
describe('menu', () => {
let page: MenuPage;
beforeEach(function() {
page = new MenuPage();
});
describe('keyboard events', () => {
beforeEach(() => {
// click start button to avoid tabbing past navigation
page.start().click();
page.pressKey(protractor.Key.TAB);
});
it('should auto-focus the first item when opened with keyboard', () => {
page.pressKey(protractor.Key.ENTER);
page.expectFocusOn(page.items(0));
});
it('should focus subsequent items when down arrow is pressed', () => {
page.pressKey(protractor.Key.ENTER);
page.pressKey(protractor.Key.DOWN);
page.expectFocusOn(page.items(1));
});
});
});
/*----- menu-page.ts -------*/
pressKey(key: any): void {
browser.actions().sendKeys(key).perform();
}
expectFocusOn(el: ElementFinder): void {
expect(browser.driver.switchTo().activeElement().getInnerHtml())
.toBe(el.getInnerHtml());
}
End to end test with axe-core
import * as axe from "axe-core";
it("should have no accessibility violations", done => {
browser.executeScript(axe.source);
// Run A11Y tests in the browsers event loop.
browser
.executeAsyncScript((resolve: any) => {
return (
new Promise() <
axe.AxeResults >
(res => {
axe.a11yCheck(document, {}, resolve);
})
);
})
.then((results: any) => {
if (results.violations.length > 0) {
console.log(results.violations);
}
expect(results.violations.length).toBe(0);
done();
});
});
Similar with all web frameworks
Component Accessibility Contract
Redirect Human Resources
Extra a11y muscle
prevent broken experiences
Automatic testing of WCAG undoubtedly contributes to both quality and efficiency, but it often reveals only the tip of the iceberg. I believe human evaluation and user testing are absolutely necessary when we work on creating solutions that can be used by everyone in any situation. The effect of seeing and knowing the problems associated with disability itself should also not be underestimated - Anders Skifte
Extensions
QUESTIONS?
Alexander Vassbotn Røyne-Helgesen
Manager, Front-end Developer @ Bekk
Accessibility testing for developers
By Alexander Vassbotn Røyne-Helgesen
