Migration

— by Youcef MADADI, FREELANCER & PROJECT MANAGER

Who am I?

an IT enthusiast who is intrested in the web dev industry and its technology

Index for 1st session

Introduction

Migration and changes

New Elements

Practice

Introduction to Angular

What is Angular?

A TypeScript-based open-source framework.
Developed and maintained by Google.
Ideal for building scalable and dynamic single-page applications (SPAs).

Component-Based Architecture:
- Reusable UI components.
Two-Way Data Binding:
- Syncs data between the model and view.
Dependency Injection:
- Simplifies managing app dependencies.
Built-In Tools:
- Routing, HTTP services, and forms.

Why Angular?

Modular Structure:
- Organizes code into modules.
Directives:
- Customizes HTML behavior.
Pipes:
- Transforms data in templates.
Reactive Programming:
- State management with RxJS (Older versions) and Signals (New versions).
Optimized Rendering:
- Improved with Angular 17/18.

Key Features

Comparison with Other Frameworks

Feature	Angular	React	Vue
Language	TypeScript	JavaScript	JavaScript
Learning Curve	Moderate	Steep	Easy
Core Strength	Full framework	UI library	Versatile

Handles complex forms (e.g., claim submissions).
Supports dynamic dashboards for real-time policy tracking.
Built for scalable and secure enterprise applications.

Why AXA needs

Angular?

Prequisit

JavaScript Basics:

Variables, functions, and event handling.
ES6+ concepts like arrow functions, destructuring, and modules.

1.

TypeScript Basics:

Strong typing: interfaces, classes, and enums.
Familiarity with decorators.

2.

HTML & CSS:

Understanding of HTML structure.
Basic CSS for styling components.

3.

Node.js and npm:

Installing and using Node.js.
Knowledge of npm for managing dependencies.

4. Angular Updates from Versions <16 to 17 & 18

General Philosophy of Angular Updates focused mainly on:

Performance Enhancements: Faster and lighter applications.
Simplification: Reducing boilerplate and improving developer experience.
Modern Features: Embracing cutting-edge web technologies.

Signals for State Management

Reactive primitives to manage state in a simpler, more declarative way.
Alternative to RxJS Observables for state updates.

Minimal boilerplate compared to Observables.
Intuitive API for tracking and reacting to state changes.

import { signal } from '@angular/core';
const count = signal(0);
count.set(1); // Updates the state

Angular 17:
- Faster runtime with Partial Hydration:
  - Only necessary components are hydrated, improving performance.
- Improved debugging for hydration mismatches.

Enhanced Client-Side Rendering (CSR)

Angular 18:
- Advanced preloading strategies for CSR optimization.
- Support for Edge Rendering.

Enhanced tree-shakable providers to reduce application size.
Improved debugging for DI errors.

Optimized Dependency Injection (DI)

Cleaner syntax than ngIf/ngFor.

Simplified Structural Directives (`@for` and `@if`)

<!-- Old Way -->
<div *ngIf="condition"></div>

<!-- New Way -->
@if (condition) {
  <div></div>
}

Lazy Loading

Improved performance with fine-grained control over module preloading.

const routes: Routes = [
  {
    path: 'customers',
    loadChildren: () =>
      import('./customers/customers.module')
      .then((m) => m.CustomersModule),
  },
];

Let's setup a new project

What Are Angular Decorators?

@Component({
  selector: 'app-example',
  template: '<p>Hello, world!</p>'
})
export class ExampleComponent {}

Special TypeScript feature for attaching metadata to classes, methods, properties, or parameters.
Widely used in Angular to define building blocks like components, directives, and services.

Help Angular understand how to process and instantiate elements in your app.

Types of Decorators
- Class: @Component, @Directive, @Injectable, @Pipe.
- Property: @Input, @Output.
- Method: @HostListener.
- Parameter: @Inject.

Key Benefits
- Reduces boilerplate.
- Enables declarative programming.
- Improves code modularity.

Understanding `@Component`

Key Metadata Properties

selector:
- Defines how the component is called in HTML.
- Example: <app-example></app-example>.
template / templateUrl:
- Inline HTML or external HTML file defining the UI.
styles / styleUrls:
- Inline styles or external CSS/SCSS files for the component.
standalone:
- Declares if the component is independent of @NgModule.
imports (if standalone):
- Specifies modules, components, directives, or pipes used in the component.

A class decorator in Angular that marks a class as a component.
Provides metadata about how the component should be processed, instantiated, and used.

@Component({
  selector: 'app-example',
  templateUrl: './example.component.html',
  styleUrls: './example.component.css',
  standalone: true,
  imports: [ComponentA, FormsModule]
})
export class ExampleComponent {}

State Management - Normal State vs. Signals

export class CounterComponent {
  count: number = 0;

  increment() {
    this.count++;
  }

  decrement() {
    this.count--;
  }
}

Automatically track dependencies.
Simplify state updates and reduce boilerplate.

Traditionally managed using class variables in components.
State changes trigger Angular's change detection to update the DOM.

import { Component, signal } from '@angular/core';

@Component({
  selector: 'app-counter',
  template: `
    <h1>{{ count() }}</h1>
    <button (click)="increment()">Increment</button>
    <button (click)="decrement()">Decrement</button>
  `,
})
export class CounterComponent {
  count = signal(0);

  increment() {
    this.count.set(this.count() + 1);
  }

  decrement() {
    this.count.set(this.count() - 1);
  }
}

Passing Props with `@Input` and `input<T>()`

<app-child [prop]="valueFromParent"></app-child>

using @Input:

import { Component, Input } from '@angular/core';

@Component({
  selector: 'app-child',
  template: `<p>Received: {{ prop }}</p>`
})
export class ChildComponent {
  @Input() prop!: string;
}

Passing Props with `@Input` and `input<T>()`

<app-child [prop]="valueFromParent"></app-child>

using @Input:

import { Component, Input, input } from '@angular/core';

@Component({
  selector: 'app-child',
  template: `<p>Received: {{ prop() }}</p>`
})
export class ChildComponent {
  prop = input<string>();
}

When to Use Which?

Feature	Use Case
`@Input`	Simple, non-reactive data binding.
`input<T>()`	For reactive, signal-based workflows with real-time updates.

Angular Lifecycle Hooks

Lifecycle Hooks are special methods in Angular that allow you to tap into key phases of a component or directive's lifecycle.
Helps manage initialization, change detection, cleanup, and more.

import { Component, OnInit, OnDestroy } from '@angular/core';

@Component({
  selector: 'app-example',
  template: `<p>Lifecycle Example</p>`,
})
export class ExampleComponent implements OnInit, OnDestroy {
  timer: any;

  ngOnInit() {
    console.log('Component initialized!');
    this.timer = setInterval(() => console.log('Timer running...'), 1000);
  }

  ngOnDestroy() {
    console.log('Component destroyed!');
    clearInterval(this.timer); // Cleanup resources
  }
}

Angular Lifecycle Hooks

Lifecycle Hooks are special methods in Angular that allow you to tap into key phases of a component or directive's lifecycle.
Helps manage initialization, change detection, cleanup, and more.

import { Component, Input, OnChanges, SimpleChanges } from '@angular/core';

@Component({
  selector: 'app-child',
  template: `<p>Current Value: {{ value }}</p>`
})
export class ChildComponent implements OnChanges {
  @Input() value: string = '';  // Input property

  ngOnChanges(changes: SimpleChanges): void {
    // Detecting changes in input properties
    if (changes['value']) {
      const prevValue = changes['value'].previousValue;
      const currentValue = changes['value'].currentValue;
      console.log(`Input 'value' changed from ${prevValue} to ${currentValue}`);
    }
  }
}

Routing for Angular 17+

import { provideRouter } from '@angular/router';

bootstrapApplication(AppComponent, {
  providers: [provideRouter(routes)],
});

Standalone Component Routing:

import { Routes } from '@angular/router';

export const routes: Routes = [
  { path: '', component: HomeComponent },
  { path: 'about', component: AboutComponent },
  { path: '**', component: NotFoundComponent }, // Wildcard route
];

No need to define @NgModule for routing.

Routing for Angular 17+

<nav>
  <a routerLink="/">Home</a>
  <a routerLink="/about">About</a>
</nav>
<router-outlet></router-outlet>

To navigate

import { Routes } from '@angular/router';

export const routes: Routes = [
  { path: '', component: HomeComponent },
  { path: 'about', loadComponent:()=>{return import('./components/about.component')
  					.then(c=>c.AboutComponent)} }, // lazy
  { path: '**', component: NotFoundComponent }, // Wildcard route
];

Lazy loading

Understanding `@Injectable`

What is Dependency Injection (DI)?

DI is a design pattern used to implement inversion of control, where the framework (Angular) manages how objects are created and passed to components, services, etc.
@Injectable marks a class as a service or provider that can be injected into other classes.

How `@Injectable` Works:

Angular creates an instance of the class and injects its dependencies when required.
The class can have services or other providers injected into its constructor.

@Injectable is a decorator used in Angular to mark a class as available for dependency injection (DI).
It tells Angular that this class can have dependencies injected into it, making it part of the Angular Dependency Injection system.
Commonly used for services, but can be applied to any class that Angular needs to manage.

@Injectable({
  // Makes the service available app-wide
  providedIn: 'root'
})
export class DataService {
  constructor() {
    console.log('DataService created');
  }

  getData() {
    return 'Data from DataService';
  }
}

Angular Services

ng generate service data

import { Injectable } from '@angular/core';

@Injectable({
  providedIn: 'root', // Singleton service at the root level
})
export class DataService {
  private data: string[] = [];

  getData() {
    return this.data;
  }

  addData(item: string) {
    this.data.push(item);
  }
}

A reusable class in Angular that encapsulates business logic, data fetching, or shared functionality.
Promotes separation of concerns by keeping components focused on the UI.

Angular Services

import { Component,signal } from '@angular/core';
import { DataService } from './data.service';

@Component({
  selector: 'app-example',
  template: `<p>{{ items }}</p>`,
})
export class ExampleComponent implements OnInit {
  items=signal<string[]>([]);
  dataService= inject(DataService)

  ngOnInit( ) :void{
    this.items.set(this.dataService.getData());
  }
}

how to inject it in lifecycle

Angular Services

export class DataService {
  private data: string[] = [];
  http= inject(HttpClient)

  getFromApi( ){
   	this.http.get('https://url')
  }

  addData(item: string) {
    this.data.push(item);
  }
}

Using API

providers:[
	provideHttpClient, // it has to be added to the configuration
    ...
]

Angular Services

import { Component,signal } from '@angular/core';
import { DataService } from './data.service';

@Component({
  selector: 'app-example',
  template: `<p>{{ items }}</p>`,
})
export class ExampleComponent implements OnInit {
  items = signal<string[]>([]);
  dataService= inject(DataService)

  ngOnInit( ) :void{
  	this.dataService.getFromApi()
    .pipe(catchError(console.error))
    .subscribe(data=>{
    	this.items.set(data);
    })
  }
}

Using API

Routing guard (using Injectable)

ng generate guard auth

import { Injectable } from '@angular/core';
import { CanActivate, Router } from '@angular/router';

@Injectable({ providedIn: 'root' })
export class AuthGuard implements CanActivate {
  constructor(private router: Router) {}

  canActivate(): boolean {
    const isLoggedIn = !!localStorage.getItem('token');
    if (!isLoggedIn) {
      this.router.navigate(['/login']);
    }
    return isLoggedIn;
  }
}

Route Guards control access to routes based on specific conditions.

 {  path: 'dashboard', component: DashboardComponent, canActivate: [AuthGuard] }

Directives

Directives are classes in Angular that allow you to add behavior to elements in the DOM.
They are a powerful way to extend HTML capabilities without changing the structure of the HTML elements.
Three types of directives:
1. Component Directives: Directives with templates (essentially components).
2. Structural Directives: Modify the structure of the DOM (e.g., *ngIf, *ngFor).
3. Attribute Directives: Change the appearance or behavior of elements (e.g., ngClass, ngStyle).

Component Directives

@Component({
  selector: 'app-example',
  templateUrl: './example.component.html',
  styleUrls: './example.component.css',
  standalone: true,
  imports: [ComponentA, FormsModule]
})
export class ExampleComponent {}

These directives are a special kind of directive with their own templates and logic.
Components are essentially directives with templates.
Example: @Component decorated classes.

Structural Directives

<div *ngIf="isVisible">Content is visible</div>

Structural directives alter the layout or structure of the DOM by adding or removing elements.
They typically start with *.

<ul>
  <li *ngFor="let item of items">{{ item }}</li>
</ul>

Attribute Directives

import { Directive, input, effect, inject, ElementRef } from '@angular/core';

@Directive({
  selector: '[appHighlighted]',
  standalone: true,
})
export class HighlightedDirective {
  isHighlighted = input(false);
  el = inject(ElementRef);
  stylesEffect = effect(() => {
    if (this.isHighlighted()) {
      this.el.nativeElement.style.backgroundColor = '#d3f9d8';
      this.el.nativeElement.style.color = '#6c757d';
    } else {
      this.el.nativeElement.style.backgroundColor = '#fff';
      this.el.nativeElement.style.color = '#000';
    }
  });
}

Structural directives alter the layout or structure of the DOM by adding or removing elements.
They typically start with *.

New Control Flow Directives with Signals in Angular 17+

Angular 17 introduces signal-based structural directives:
- @if: Conditionally renders content based on the signal’s value.
- @for: Iterates over a collection of signals.
These directives enable more powerful and reactive template management using signals.

`@if` with Signals

@if(signal)
  <p>Content to display when signal is true</p>

@if is a signal-aware directive that conditionally renders content when a signal’s value changes.
This is similar to *ngIf but works specifically with Angular's signal system.

@if (isLoading()) {
	<p>Loading...</p>
}

syntax:

html:

`@for` with Signals

@for(item of signal; track item.index)
  <p>{{ item }}</p>

The @for directive iterates over a signal that returns an iterable collection (like an array or list).
It allows you to directly bind to a signal that updates reactively.

@for(item of todoItems(); track item.id) {
  <li>{{ item }}</li>
}

syntax:

html:

`@if @else if, @else`

@if(condition)
  <p>Content to display when condition is true</p>
@else if(condition2)
  <p>Content to display when condition2 is true</p>
@else
  <p>Content to display when no condition is true</p>

@if (isLoading()) {
  <p>Loading...</p>
} else {
  <ul>
    @for (let item of todoItems()) {
      <li>{{ item }}</li>
    }
  </ul>
}

syntax:

html:

the `output` Function in Angular 17+

output is a new function in Angular 17+ that replaces the traditional @Output decorator.
It is used for emitting events or signals from a component.
Unlike @Output, the output function allows you to directly define signal-based outputs for event handling.

Creating an Event Emitter with `output`

import { Component, signal, output } from '@angular/core';

@Component({
  selector: 'app-child',
  template: `<button (click)="sendData()">Send Data</button>`,
})
export class ChildComponent {
  // Creating an output signal using the output function
  sendDataSignal = output<string>();

  sendData() {
    // Emitting the data signal when the button is clicked
    this.sendDataSignal.emit('Hello from Child!');
  }
}

child component:

Listening for Events in the Parent Component

@Component({
  selector: 'app-parent',
  template: `<app-child (sendDataSignal)="handleData($event)"></app-child>`,
})
export class ParentComponent {
  handleData(data: string) {
    console.log('Received from child:', data);
  }
}

parent component:

Declarative and Simpler: The output function offers a more declarative and streamlined approach for emitting events.
No Need for Decorators: You no longer need to use the @Output decorator.
Signal-based Communication: Fully integrated with Angular’s new signal-based reactivity system.
Enhanced Performance: Provides a more lightweight and performant solution compared to traditional EventEmitter.

Advantages of Using `output` Function

.Forms

Forms in Angular are managed using Reactive Forms and Template-driven Forms, both of which require certain modules to function properly.

Angular provides two types of form handling mechanisms:

Template-driven Forms: Managed using FormsModule.
Reactive Forms: Managed using ReactiveFormsModule.

import { FormsModule } from '@angular/forms';

import { ReactiveFormsModule } from '@angular/forms';

Standalone Component with Reactive Forms

import { Component, OnInit } from '@angular/core';
import { ReactiveFormsModule, FormBuilder, Validators, FormGroup } from '@angular/forms';

@Component({
  selector: 'app-my-form',
  standalone: true,
  imports: [ReactiveFormsModule],  // Importing ReactiveFormsModule directly
  templateUrl: './my-form.component.html',
})
export class MyFormComponent implements OnInit {
  myForm: FormGroup;

  constructor(private fb: FormBuilder) {}

  ngOnInit() {
    this.myForm = this.fb.group({
      name: ['', Validators.required],
      email: ['', [Validators.required, Validators.email]],
    });
  }

  onSubmit() {
    if (this.myForm.valid) {
      console.log(this.myForm.value);
    }
  }
}

Standalone Component with Reactive Forms

<form [formGroup]="myForm" (ngSubmit)="onSubmit()">
  <label for="name">Name:</label>
  <input id="name" formControlName="name" type="text" />

  <label for="email">Email:</label>
  <input id="email" formControlName="email" type="email" />

  <button type="submit" [disabled]="!myForm.valid">Submit</button>
</form>

Pipes in Angular

Pipes in Angular are used for transforming data in templates.
A pipe takes in data and transforms it to another format for display.
They are typically used in the HTML template to format, filter, or manipulate the data being displayed.

ng g pipe name

command:

{{ value | pipeName:parameter }}

syntax:

Built-in Pipes in Angular

{{ today | date:'short' }}

Date Pipe: Formats date values.

{{ amount | currency:'USD' }}

Currency Pipe: Transforms numbers into currency format

{{ 'hello' | uppercase }}

Uppercase and Lowercase Pipes: Transforms text to uppercase or lowercase.

{{ user | json }}

JSON Pipe: Converts objects to JSON format.

Built-in Pipes in Angular

import { Pipe, PipeTransform } from '@angular/core';

@Pipe({
  name: 'reverseString'
})
export class ReverseStringPipe implements PipeTransform {
  transform(value: string): string {
    return value.split('').reverse().join('');
  }
}

ng g pipe reverseString

{{ 'hello' | reverseString }}

Pure vs Impure Pipes

Pure Pipes
- Pure Pipes are only re-evaluated when the input data changes.
- They are optimized and efficient because Angular caches their result unless the input changes.

@Pipe({
  name: 'reverseString',
  pure: true
})

Impure Pipes
- Impure Pipes are evaluated on every change detection cycle, regardless of whether the input changes.
- They are useful when you need to check for changes in more complex data structures like arrays or objects.

@Pipe({
  name: 'reverseString',
  pure: false
})

Async Pipe

The async pipe is a built-in pipe that subscribes to an observable or promise and returns the latest value.
It automatically handles subscriptions and unsubscriptions.

<div>{{ observableData | async }}</div>

It displays the latest value emitted by the observable observableData.

State optimization with 'Computed'

The computed() function is a part of Angular's new Signals API introduced in Angular 16.
It allows you to define derived or computed state that automatically updates when its dependencies (signals) change.

Reactive Dependencies: Automatically reacts to changes in the state.
Derived State: Simplifies logic by creating a state that depends on other signals.
Efficient Updates: Only recomputes when its dependencies change.

Why and when?

Eliminates the need for manual state management.
Keeps the application logic concise and reactive.
Improves performance by recalculating only when needed.

State optimization with 'Computed'

import { Component, signal, computed } from '@angular/core';

@Component({
  selector: 'app-counter',
})
export class CounterComponent {
  // Define a signal for the counter
  count = signal(0);

  // Create a computed signal for derived state
  doubleCount = computed(() => this.count() * 2);

  // Another computed signal to check if the count is even
  isEven = computed(() => this.count() % 2 === 0 ? 'Yes' : 'No');

  // Increment the counter
  increment() {
    this.count.set(this.count() + 1);
  }
}

Let's practice

THANK YOU

Contact me via email or Discord if you have any questions.

@jesuph

madadiyoucef@outlook.com

Angular training - Migration

By Youcef Madadi

Angular training - Migration

Youcef Madadi

Web and game development teacher

Migration

— by Youcef MADADI, FREELANCER & PROJECT MANAGER

Who am I?

Index for 1st session

Introduction to Angular

What is Angular?

Why Angular?

Key Features

Comparison with Other Frameworks

Why AXA needs

Angular?

Prequisit

1.

2.

3.

4.

Angular Updates from Versions <16 to 17 & 18

Signals for State Management

Enhanced Client-Side Rendering (CSR)

Optimized Dependency Injection (DI)

Simplified Structural Directives (@for and @if)

Lazy Loading

Let's setup a new project

What Are Angular Decorators?

Key Benefits

Reduces boilerplate.

Enables declarative programming.

Improves code modularity.

Understanding @Component

State Management - Normal State vs. Signals

Passing Props with @Input and input<T>()

using @Input:

Passing Props with @Input and input<T>()

using @Input:

When to Use Which?

Angular Lifecycle Hooks

Angular Lifecycle Hooks

Routing for Angular 17+

Standalone Component Routing:

Routing for Angular 17+

To navigate

Lazy loading

Understanding @Injectable

What is Dependency Injection (DI)?

How @Injectable Works:

Angular Services

Angular Services

Angular Services

Angular Services

Routing guard (using Injectable)

Directives

Component Directives

Structural Directives

Attribute Directives

New Control Flow Directives with Signals in Angular 17+

@if with Signals

@for with Signals

@if @else if, @else

the output Function in Angular 17+

Creating an Event Emitter with output

Listening for Events in the Parent Component

Advantages of Using output Function

.Forms

Standalone Component with Reactive Forms

Standalone Component with Reactive Forms

Pipes in Angular

Built-in Pipes in Angular

Built-in Pipes in Angular

Pure vs Impure Pipes

Pure Pipes

Impure Pipes

Async Pipe

State optimization with 'Computed'

Why and when?

State optimization with 'Computed'

THANK YOU

Contact me via email or Discord if you have any questions.

Angular training - Migration

More from Youcef Madadi

Simplified Structural Directives (`@for` and `@if`)

Understanding `@Component`

Passing Props with `@Input` and `input<T>()`

Passing Props with `@Input` and `input<T>()`

Understanding `@Injectable`

How `@Injectable` Works:

`@if` with Signals

`@for` with Signals

`@if @else if, @else`

the `output` Function in Angular 17+

Creating an Event Emitter with `output`

Advantages of Using `output` Function
