Non-Euclidean Motion Planning with Graphs of Geodesically-Convex Sets

Thomas Cohn, Mark Petersen, Max Simchowitz, Russ Tedrake

Motion Planning Today

  • Sampling-based planning
    • +
       Global (probabilistic) completeness
    • -
       "Curse of Dimensionality"
    • -
       Non-smooth paths
  • Trajectory optimization
    • -
       Nonconvex
    • +
       Scales with dimension
    • +
       Smooth paths, dynamics

Motion Planning, Wikipedia

Motion Planning Today

  • Sampling-based planning
    • +
       Global (probabilistic) completeness
    • -
       "Curse of Dimensionality"
    • -
       Non-smooth paths
  • Trajectory optimization
    • -
       Nonconvex
    • +
       Scales with dimension
    • +
       Smooth paths, dynamics

Common challenge: collision avoidance

Motion Planning, Wikipedia

  • Sampling-based planning
    • +
       Global (probabilistic) completeness
    • -
       "Curse of Dimensionality"
    • -
       Non-smooth paths
  • Trajectory optimization
    • -
       Nonconvex
    • +
       Scales with dimension
    • +
       Smooth paths, dynamics

Planning through Convex Sets

Motion Planning around Convex Obstacles with Convex Optimization, Marcucci et. al.

Obstacle avoidance: nonconvex

Safe-set containment: convex

Obstacle avoidance guarantees!

  • Piecewise-linear trajectories: just check endpoints
  • Bezier curves: check control points

Motion Planning with GCS

  • Represent C-Free with convex sets
  • Formulate shortest path problem as MICP
  • Can solve to optimality (branch and bound)
  • In practice, relax and round yields a good result

Shortest Paths in Graphs of Convex Sets, Marcucci et. al.

Motion Planning around Convex Obstacles with Convex Optimization, Marcucci et. al.

What about non-Euclidean configuration spaces?

Configuration Space as a Manifold

Trajectory Optimization on Manifolds: A Theoretically-Guaranteed Embedded Sequential Convex Programming Approach, Bonalli et. al.

Configuration Space as a Manifold

Trajectory Optimization on Manifolds: A Theoretically-Guaranteed Embedded Sequential Convex Programming Approach, Bonalli et. al.

\(\mathcal{Q}\)



Configuration Space as a Manifold

Trajectory Optimization on Manifolds: A Theoretically-Guaranteed Embedded Sequential Convex Programming Approach, Bonalli et. al.

\(\mathcal{Q}\)



\(\overline{\mathcal{M}}\subseteq\mathcal{Q}\)

(Collision free subset)

Shortest-Path Planning along a Manifold

Trajectory Optimization on Manifolds: A Theoretically-Guaranteed Embedded Sequential Convex Programming Approach, Bonalli et. al.

\[\begin{array}{rl}    \argmin & L(\gamma)\\    \textrm{subject to} & \gamma\in\mathcal{C}^{1}_{\operatorname{pw}}([0,1],\overline{\mathcal{M}})\\    & \gamma(0)=p\\    & \gamma(1)=q\end{array}\]

Shortest-Path Planning along a Manifold

\[\begin{array}{rl}    \argmin & L(\gamma)\\    \textrm{subject to} & \gamma\in\mathcal{C}^{1}_{\operatorname{pw}}([0,1],\bar{\mathcal{M}})\\    & \gamma(0)=p\\    & \gamma(1)=q\end{array}\]

Minimize arc length

Path must be

piecewise-differentiable

Start at point \(p\)

Finish at point \(q\)

Computing Shortest Paths

  1. Formulate GCS on a Manifold




  2. Transform Problem back into Euclidean Space




  3. Additional requirements to ensure convexity

Results: PR2 Whole-Body Plans

Robot Operating System (ROS), Picknik

Non-Euclidean Motion Planning with Graphs of Geodesically-Convex Sets

Thomas Cohn, Mark Petersen, Max Simchowitz, Russ Tedrake
