MXnet to onnx to ml.net

Cosmin Catalin Sanda

th

4   April 2019

TOPICs

  • About me
  • Machine Learning in .NET
  • The ONNX interchange format
  • ML workflow in AWS

ABOUT ME

Cosmin Catalin Sanda

             Data Scientist and Engineer at AudienceProject

Blogging at https://cosminsanda.com

Machine learning in .NET before 2018

...THEN something happened

In early 2018 Microsoft open-sourced ML.NET

  • Heavily supported by Microsoft
  • A great generalist framework
  • No deep learning capabilities
  • ONNX support

What is ONNX

Open source interchange format between ML models

  • Model using one language/library you want and Infer using another language/library you want
  • Performance
  • Some limitations apply

Typical Workflow

  • Model a regression problem using MXNet
  • Export awesome model to ONNX
  • Use ONNX model for real-time inference in a .NET application

Unfortunately there's a but

ONNX scoring in ML.NET works only on Windows X64 platforms (currently)

ML pipeline components

  • Amazon Sagemaker for building the model
  • Amazon S3 for storing the model
  • AWS EC2 for building the application image using Windows containers
  • AWS Elastic Container Registry for storing the Docker image
  • AWS Elastic Container Service for running the Docker image
  • Remote Desktop Connection client
  • Internet browser

Amazon SAGEMAKER

MXNet Model & DATA

from mxnet.gluon.nn import HybridSequential, Dense, Dropout

net = HybridSequential()
with net.name_scope():
    net.add(Dense(9))
    net.add(Dropout(.25))
    net.add(Dense(16))
    net.add(Dropout(.25))
    net.add(Dense(1))

Kaggle's New York City Taxi Fare Prediction

MXNET to onnx

from mxnet.contrib import onnx as onnx_mxnet

def save(net, model_dir):
    net.export("model", epoch=4)
    onnx_mxnet.export_model(sym="model-symbol.json",
                            params="model-0004.params",
                            input_shape=[(1, 4)],
                            input_type=np.float32,
                            onnx_file_path="{}/model.onnx".format(model_dir),
                            verbose=True)

Model artifact (archive) is uploaded to S3 by Sagemaker

building the .net application

  • Use your own Windows x64 installation
  • Provision a Window EC2 instance

Two options for developing

PROVISIONED tools

  • Docker
  • AWS CLI

Making predictions in ml.net using onnx

MLContext _env = env;
string _onnxFilePath = onnxFilePath;

var pipeline = new ColumnConcatenatingEstimator(_env, "Features", "RateCode", "PassengerCount", "TripTime", "TripDistance")
    .Append(new ColumnSelectingEstimator(_env, "Features"))
    .Append(new OnnxScoringEstimator(_env, _onnxFilePath, "Features", "Estimate"))
    .Append(new ColumnSelectingEstimator(_env, "Estimate"))
    .Append(new CustomMappingEstimator<RawPrediction, FlatPrediction>(_env, contractName: "OnnxPredictionExtractor",
        mapAction: (input, output) =>
        {
            output.Estimate = input.Estimate[0];
        }));

var transformer = pipeline.Fit(data);

Dockerizing

FROM microsoft/dotnet:sdk AS build-env
COPY inference/*.csproj /src/
COPY inference/*.cs /src/
WORKDIR /src
RUN dotnet restore --verbosity normal
RUN dotnet publish -c Release -o /app/ -r win10-x64

FROM microsoft/dotnet:aspnetcore-runtime
COPY --from=build-env /app/ /app/
COPY models/model.onnx /models/
COPY lib/* /app/
WORKDIR /app
CMD ["dotnet", "inference.dll", "--onnx", "/models/model.onnx"]

RUNNING inference on AWS

  • Create Docker registry in AWS ECR
  • Push local image to ECR
  • Create Windows Docker cluster in AWS ECS
  • Configure task and run the application

KEY takeAways

  • ONNX gives flexibility and power when using deep learning libraries
  • Docker works for Windows native apps
  • ML.NET is a great framework for doing cross-platform development on .NET Core
