Learning Hamiltonians of constrained mechanical systems
Davide Murari
One day – Young Researchers Seminars, Maths Applications & Models
davide.murari@ntnu.no
Joint work with Elena Celledoni, Andrea Leone and Brynjulf Owren
Definition of the problem
x˙(t)=f(x(t))∈Rm
\dot{x}(t) = f(x(t))\in\mathbb{R}^m
GOAL : approximate the unknown f on Ω
DATA:
{(xi,yi1,...,yiM)}i=1,...,N,xi∈Ω⊂Rm
\{(x_i,y_i^1,...,y_i^M)\}_{i=1,...,N},\\
x_i\in\Omega\subset\mathbb{R}^m
yij=ΦfjΔt(xi)+δij
y_i^j = \Phi_f^{j\Delta t}(x_i) + \delta_i^j
Δt>0
\Delta t>0
Approximation of a dynamical system
Introduce a parametric model
x˙(t)=f^θ(x(t))
\dot{x}(t) = \hat{f}_{\theta}(x(t))
solveminθ∑i=1N∑j=1Myij−y^ij2=minθLθ
\text{solve}\quad \min_{\theta} \sum_{i=1}^N \sum_{j=1}^M \left\|y_i^j - \hat{y}_i^{j}\right\|^2 = \min_{\theta}\mathcal{L}_{\theta}
1️⃣
3️⃣
Choose any numerical integrator applied to f^θ
y^i0=xi,y^ij+1=ΨθΔt(y^ij)
\hat{y}_i^0 = x_i,\,\,\hat{y}_i^{j+1} = \Psi_{\theta}^{\Delta t}(\hat{y}_i^{j})
2️⃣
Li
\mathcal{L}_i
Unconstrained Hamiltonian systems
f(q,p)=J∇H(q,p)=[∂pH(q,p)−∂qH(q,p)],
f(q,p) = \mathbb{J}\nabla H(q,p)=\begin{bmatrix} \partial_p H(q,p) \\ -\partial_q H(q,p)\end{bmatrix},
H:R2n→R,J=[0n−InIn0n]∈R2n×2n
H:\mathbb{R}^{2n}\rightarrow\mathbb{R},\quad \mathbb{J} = \begin{bmatrix} 0_n & I_n \\ -I_n & 0_n \end{bmatrix}\in\mathbb{R}^{2n\times 2n}
Unconstrained Hamiltonian systems
f(q,p)=J∇H(q,p)=[∂pH(q,p)−∂qH(q,p)],
f(q,p) = \mathbb{J}\nabla H(q,p)=\begin{bmatrix} \partial_p H(q,p) \\ -\partial_q H(q,p)\end{bmatrix},
H:R2n→R,J=[0n−InIn0n]∈R2n×2n
H:\mathbb{R}^{2n}\rightarrow\mathbb{R},\quad \mathbb{J} = \begin{bmatrix} 0_n & I_n \\ -I_n & 0_n \end{bmatrix}\in\mathbb{R}^{2n\times 2n}
Choice of the model:
f^θ(q,p)=J∇Hθ(q,p)
\hat{f}_{\theta}(q,p) = \mathbb{J}\nabla H_{\theta}(q,p)
Hθ(q,p)=21pTATAp+Netθˉ(q),θ=(A,θˉ)
H_{\theta}(q,p) = \frac{1}{2}p^TA^TAp + Net_{\bar{\theta}}(q),\quad \theta = (A,\bar{\theta})
Netθˉ(q)
Netθˉ(q)=Nθˉk∘...∘Nθˉ1(q)
Net_{\bar{\theta}}(q) = \mathcal{N}_{\bar{\theta}_k} \circ ... \circ \mathcal{N}_{\bar{\theta}_1}(q)
Nθˉi(q)=Σ(Aiq+bi)
\mathcal{N}_{\bar{\theta}_i}(q) = \Sigma(A_iq + b_i)
Σ(q)=[σ(q1),...,σ(qn)],σ:R→R
\Sigma(q) = [\sigma(q_1),...,\sigma(q_n)],\\
\sigma:\mathbb{R}\rightarrow\mathbb{R}
Measuring the approximation quality
E1=∑i=1Nˉ∑j=1Mˉzij−z^ij2
\mathcal{E}_1 = \sum_{i=1}^{\bar{N}}\sum_{j=1}^{\bar{M}}\left\|z_i^j - \hat{z}_i^j\right\|^2
zij+1=Ψ~HΔt(zij),z^ij+1=Ψ~HθΔt(z^ij)
z_i^{j+1} = \tilde{\Psi}^{\Delta t}_{H}(z_i^j),\quad \hat{z}_i^{j+1} = \tilde{\Psi}^{\Delta t}_{H_{\theta}}(\hat{z}_i^j)
E2=Nˉ1∑i=1NˉH(xˉi)−Hθ(xˉi)−Nˉ1∑l=1Nˉ(H(xˉl)−Hθ(xˉl))
\mathcal{E}_{2}=\frac{1}{\bar{N}} \sum_{i=1}^{\bar{N}}\left|H\left(\bar{x}_{i}\right)-H_{\theta}\left(\bar{x}_{i}\right)-\frac{1}{\bar{N}} \sum_{l=1}^{\bar{N}}\left(H\left(\bar{x}_{l}\right)-H_{\theta}\left(\bar{x}_{l}\right)\right)\right|
z^i0=zi0=xˉi
\hat{z}_i^0 = z_i^0 = \bar{x}_i
Test initial conditions
Numerical experiment
H(q,p)=21[p1p2]T[5−1−15][p1p2]+4q14+q24+2q12+q22
H(q, p)=\frac{1}{2}\left[\begin{array}{ll}
p_{1} & p_{2}
\end{array}\right]^{T}\left[\begin{array}{cc}
5 & -1 \\
-1 & 5
\end{array}\right]\left[\begin{array}{l}
p_{1} \\
p_{2}
\end{array}\right]+\frac{q_{1}^{4}+q_{2}^{4}}{4}+\frac{q_{1}^{2}+q_{2}^{2}}{2}
⚠️ The integrator used in the test, can be different from the training one.
Constrained Hamiltonian systems
{x˙(t)=J∇H(q,p),x=(q,p)g(q)=0,g:Rn→Rm
\begin{cases}
\dot{x}(t) = \mathbb{J}\nabla H(q,p),\quad x=(q,p)\\
g(q) = 0,\quad g:\mathbb{R}^n\rightarrow\mathbb{R}^m
\end{cases}
M =T∗Q=T∗{q∈Rn:g(q)=0}={(q,p)∈R2n:g(q)=0,G(q)∂pH(q,p)=0}
\mathcal{M} = T^*\mathcal{Q}=T^*\{q\in\mathbb{R}^n:\,g(q)=0\} = \\
\{(q,p)\in\mathbb{R}^{2n}:\,g(q)=0,\,G(q)\partial_pH(q,p)=0\}
Q={q∈Rn:g(q)=0}⊂Rn
\mathcal{Q}=\{q\in\mathbb{R}^n:\;g(q)=0\}\subset\mathbb{R}^n
Modelling the vector field on M
P(q):Rn→TqQ,v↦P(q)v
P(q) : \mathbb{R}^n\rightarrow T_q\mathcal{Q},\,v\mapsto P(q)v
TqQ={v∈Rn:G(q)v=0}
T_q\mathcal{Q} = \{v\in\mathbb{R}^n:\,G(q)v=0\}
{q˙=P(q)∂pH(q,p)p˙=−P(q)T∂qH(q,p)+W(q,p)∂pH(q,p)
\begin{cases}
\dot{q}=P(q) \partial_{p} H(q, p) \\
\dot{p}=-P(q)^{T} \partial_{q} H(q, p)+W(q, p) \partial_{p} H(q, p)
\end{cases}
On M the dynamics can be written as
⚠️ On R2n∖M the vector field extends non-uniquely.
Learning constrained Hamiltonian systems
f^θ(q,p)=[P(q)∂pHθ(q,p)−P(q)T∂qHθ(q,p)+W(q,p)∂pHθ(q,p)]
\hat{f}_{\theta}(q,p) = \begin{bmatrix}
P(q) \partial_{p} H_{\theta}(q, p) \\
-P(q)^{T} \partial_{q} H_{\theta}(q, p)+W(q, p) \partial_{p} H_{\theta}(q, p)
\end{bmatrix}
Hθ(q,p)=21pTMθ1−1(q)p+Netθ2(q),θ=(θ1,θ2)
H_{\theta}(q, p)=\frac{1}{2} p^{T} M_{\theta_{1}}^{-1}(q) p+\operatorname{Net}_{\theta_{2}}(q), \\
\theta=\left(\theta_{1}, \theta_{2}\right)
Example with the double spherical pendulum
A case where preserving M helps
Suppose to have just few unknown elements in the expression of the Hamiltonian
As a consequence, one expects a very accurate approximation.
Example with the spherical pendulum:
Hθ(q,p)=2m1pTp+uTq,m>0,u∈R3
H_{\theta}(q, p)=\frac{1}{2 m} p^{T} p+u^{T} q, \quad m>0, u \in \mathbb{R}^{3}
Similar results preserving M
For interactive plots complementary
to this:
Thank you for the attention
Preprint:
Celledoni, E., Leone, A., Murari, D., & Owren, B. (2022). Learning Hamiltonians of constrained mechanical systems. arXiv preprint arXiv:2201.13254
