Choose Your Own Adventure for client web services

With

Dave Anderson

@dvndrsn

before the adventure

A little bit about me

PROLOGUE TO THE ADVENTURE

What to expect on your journey...

Choose GraphQL or REST

Review examples

Advanced Considerations

Chapter 1

API Architecture and Design

You are a developer.

If you choose a REST, advance to the next section.

One things is for sure: you need a robust API.

What do you choose?

If you choose GraphQL, advance to the following section.

Choose Rest

Architecture and Design

You choose to build your API using REST web service architecture.

Choosing REST is a familiar design decision.

Choose Rest

Architecture and Design

You use HTTP verbs semantically to describe operations on your resources

GET /api/v1/stories/
POST /api/v1/stories/
GET /api/v1/stories/{id}/
PUT /api/v1/stories/{id}/
DELETE /api/v1/stories/{id}/

Choose Rest

Architecture and Design

You build many different endpoints, for each resource.

GET, POST /api/v1/stories/
GET, PATCH, DELETE /api/v1/stories/{id}/
GET, POST /api/v1/stories/{id}/passages/
GET, PATCH, DELETE /api/v1/stories/{id}/passages/{id}/
GET, POST /api/v1/stories/{id}/passages/{id}/choices/
GET, PATCH, DELETE /api/v1/stories/{id}/passages/{id}/choices/{id}/

Choose Rest

Architecture and Design

You choose how to structure your response.

// Hypermedia as the Engine of the Application State
// HATEAOS
// GET api/v1/stories/
{
    "id": 1,
    "title": "REST",
    "author": "Dave A.",
    "description": "Can have many response structures",
    "links": [
        {
            "href": "1/passages/",
            "type": "GET",
            "rel": "passages
        },
        // ... etc
    ]
}

Choose Rest

Architecture and Design

You receive many requests to add new fields to the API.



..but now some clients are fetching fields that they don't need.



You want to deprecate old fields or refactor the structure of the API by introducing a new set of versioned endpoints.



..but now you're supporting multiple versions of each API resource forever.

Choose Rest

Architecture and Design

You are attacked by a sea monster with as many arms as your API has endpoints and versions.



You die.

Wait, wait, wait.. let's skip back and choose GraphQL.

Choose GraphQL

Architecture and Design

GraphQL is a query language for your API.



It allows clients

to ask questions of your server

and only get the data they need

in a single request.

Choose GraphQL

Architecture and Design

You define a schema...

type Story {
  id: ID,
  title: String,
  author: String,
  passages: [Passage]
}

type Passage {
  id: ID,
  name: String,
  description: String,
  is_ending: Boolean,
  choices: [Choice]
}

type Choice {
  id: ID,
  description: String,
  toPassage: Passage
}

type Query {
  story(id: ID): Story
}

Choose GraphQL

Architecture and Design

Then you write queries against that schema..

query myStory {
  story(id:1) {
    id
    title
    passages {
      id
      name
      description
    }
  }
}

Choose GraphQL

Architecture and Design

And you get a JSON response.

{
  "story": {
    "id": "1",
    "title": "Choose Your Own Adventure with GraphQL",
    passages: [
      {
        "id": "1",
        "name": "Beginning",
        description: "Your adventure begins",
      },
      {
        "id": "2",
        "name": "GraphQL Architecture",
        description: "Choose GraphQL!",
      },
      // ...
    ]
  }
}

Choose GraphQL

Architecture and Design

If you need to change data, write a mutation!

mutation newStory {
  createStory (input: {
    title: "GraphQL",
    author: "Dave A",
    description: "Its pretty cool"
  }) {
    story{
      id
      title
      description
      author
    }
  }
}

Choose GraphQL

Architecture and Design

Open sourced by Facebook in 2015.



Since open sourcing, we now have a lot of choice!



Which platform do you choose?

If you choose a Python, advance to the next section.

Seriously, choose Python, advance to the next section.

Choose Python + Graphene

Architecture and Design

You choose to use the Graphene framework in Python.

Choose Python + Graphene

Architecture and Design

Graphene Django provides some nice built in Views to handle parsing GraphQL requests.

urlpatterns = [
    ...
    path(
        'graphql/',
        GraphQLView.as_view(schema=schema,graphiql=True)
    ),
    ...
]

Choose Python + Graphene

Architecture and Design

You write your schema.

class StoryType(graphene.ObjectType):

    class Meta:
        interfaces = (graphene.Node, )

    title = graphene.String()
    description = graphene.String()
    author = graphene.String()

    passages = graphene.List(PassageType)
    ...

class Query(graphene.ObjectType):
    story = graphene.Node.Field(StoryType)
    ...

schema = graphene.Schema(query=Query)
query myStory {
  story(id:1) {
    id
    title
    passages {
      id
      name
      description
    }
  }
}

Choose Python + Graphene

Architecture and Design

You write resolvers for each of the fields.

class StoryType(graphene.ObjectType):
   ...
   def resolve_title(self, info, **args):
       return self.title
  ...


class Query(graphene.ObjectType):
    ...
    def resolve_story(self, info, **args):
        id = args.get("id")
        return Story.objects.get(id=id)
    ...
query myStory {
  story(id:1) {
    id
    title
    passages {
      id
      name
      description
    }
  }
}

Choose Python + Graphene

Architecture and Design

You write mutations for any requests that result in changes to data.

class StoryInput(graphene.InputObjectType):
    title = graphene.String(required=True)
    description = graphene.String()
    author = graphene.String()

class CreateStory(graphene.Mutation):
    class Arguments:
        input = StoryInput(required=True)

    story = graphene.Field(StoryType)

    @classmethod
    def mutate_and_get_payload(cls, root, info, **input):
        story = Story.objects.create(*input)
        return cls(story=story)

class Mutation(grapene.ObjecctType):
    create_story = graphene.Field(CreateStory)
    ...

schema = graphene.Schema(
    query=Query,
    mutation=Mutation
)
mutation newStory {
  createStory (input: {
    title: "GraphQL",
    author: "Dave A",
    description: "Its pretty cool"
  }) {
    story{
      id
      title
      description
      author
    }
  }
}

Choose Python + Graphene

Architecture and Design

You add new fields easily.

Advance to the next section to go for a space jog.

You signal for fields to be depreciated with annotations on your schema.

You modify existing fields without worrying about breaking clients.

Chapter 2

Scaling and Performance

Performance tuning can be more challenging with GraphQL.

If you choose to prefetch data, advance to the next section.

If you choose dig into other methods, advance to the following section.

StackOverflow posts are scarce in the depths of space..

Unlike REST, it is not generally possible to do HTTP level request caching.

What will be your approach?

Choose PREFETCHING DATA

Scaling and Performance

As a Django developer, prefetching data feels like the natural first step...

But it can be hard to decide

where to optimize the query...

Choose PREFETCHING

Scaling and Performance

What does an N+1 GraphQL query look like?

Stories

Story 1 passages

Story 2 -author,  passages, etc..

Passage 1 - Choices

Choice 1 - To Passage

Passage 2 - Choices, etc..

Etc..

Time

query allStories {
  stories {
    id
    title
    author {
      name
    }
    passages {
      id
      description
      choices {
        id
        description
        toPassage {
          id
          description
        }
      }
    }
  }
}

Story 1 author

Choose PREFETCHING DATA

Scaling and Performance

Let's optimize and split the difference between stories and passages..

class StoryType(graphene.ObjectType):
   ...
   def resolve_passages(self, info, **kwargs):
       return Passage.objects.filter(story=self.id) \
           .prefetch_related('to_choices__to_passage')
  ...


class Query(graphene.ObjectType):
    ...
    def resolve_story(self, info, **kwargs):
        return Story.objects.all() \
            .select_related('author')
    ...
query allStories {
  stories {
    id
    title
    author {
      name
    }
    passages {
      id
      description
      choices {
        id
        description
        toPassage {
          id
          description
        }
      }
    }
  }
}

Choose PREFETCHING

Scaling and Performance

What might our performance look like now?

Stories + author

Story 1 passages +

choices + to passage

Story 2 passages +

choices + to passage

Etc..

Etc..

Time

query allStories {
  stories {
    id
    title
    author {
      name
    }
    passages {
      id
      description
      choices {
        id
        description
        toPassage {
          id
          description
        }
      }
    }
  }
}

There must be a better way.. let's try to dig deeper.

query allStoriesOverview {
  stories {
    id
    title
    passages {
      id
      description
    }
  }
}

Choose DATALOADERS

Scaling and Performance

Looking more closely, you find that the Facebook-preferred approach is to use DataLoaders.

Graphene provides us with an implementation of both DataLoader and Promise.

Choose DATALOADERS

Scaling and Performance

DataLoaders allow for batching and caching of requested data.

class PassagesFromStoryLoader(DataLoader):

    def batch_load_fn(self, story_ids):
        return Promise.resolve(self.get_passages(story_ids))

    def get_passages(self, story_ids):
        passages = Passage.objects \
            .filter(story_id__in=story_ids)
        lookup = defaultdict(list)
        for passage in passages:
            lookup[passage.story_id].append(passage)
        return [lookup[story_id] for story_id in story_ids]

class StoryType(graphene.ObjectType):
   ...
   def resolve_passages(self, info, **kwargs):
       return info.context.passages_from_story_loader \
           .load(self.id)
  ...

Choose DataLoaders

Scaling and Performance

Batching and caching helps scale performance!

Stories

Passages (batched across Stories)

Choices (batched across Passages)

To Passage (batched across choices)

Time

query allStories {
  stories {
    id
    title
    author {
      name
    }
    passages {
      id
      description
      choices {
        id
        description
        toPassage {
          id
          description
        }
      }
    }
  }
}

Author (cached, batched across Stories)

Choose DataLoaders

Scaling and Performance

DataLoaders add some complexity, but are great for scaling performance through batching and caching.

 Let's look at some client side concerns.

Our API is finally performant and humming along.

Chapter 3

Building a client web application

Your API is now built, scaled up and ready to share with the world.

Let's chose to build an application with Apollo and React, advance to the next section.

Now its time to build a rich web client application.

Apollo and Relay are the two most popular JavaScript libraries.

Apollo is a powerful framework that allows you to focus on writing application code.

Choose APOLLO

Building a client web application

const Story = ({ loading, error, data }) => {
  if (loading) {
    return (<div>Loading the story!</div>)
  }
  if (error) {
    return (<div>There was an error: {error.message}!</div>)
  }

  return (
    <div>
      <div>Title: {data.story.title}</div>
      <div>Author: {data.story.author}</div>
      <div>Description: {data.story.description}</div>
    </div>
  )
}

const client = new ApolloClient({
  uri: 'MY_COOL_GRAPHQL_URL'
});

ReactDOM.render(
  <ApolloProvider client={client}>
    <StoryWithData storyId={1} />
  </ApolloProvider>,
  root
)
const query = gql`
  query myStory ($storyId: String) {
    story(id:$storyId) {
    id
    title
    passages {
        id
        name
        description
      }
    }
  }
`

const options = (props) => ({
  variables: {
    storyId: props.storyId,
  }
})

const withStoryData = graphql(query, {
  alias: 'withStoryData',
  options,
})

const StoryContainer = withStoryData(
  Story
)

Choose APOLLO

Building a client web application

const withCreateStory = graphql(mutation, {
  alias: 'withCreateStory',
  props: mapMutationToProps,
})

const StoryFormContainer = connect(
  withStoryData,
  withCreateStory,
)(StoryForm)

// callback is available in StoryForm component now!
// Pass in values to call the mutation.

const StoryForm = ({ handleCreateStory }) => ({
  <button
    onClick={() => handleCreateStory(
      'Title',
      'Author',
      'Description',
    )}
  >
    Create a story!
  </button>
})
const mutation = gql`
  mutation newStory ($input: StoryInput) {
    createStory (input: $input) {
      story{
        id
        title
        description
        author
      }
    }
  }
`

const mapMutationToProps = ({ mutate }) => ({
  handleCreateStory: (
    title,
    author,
    description
  ) => {
    mutate({
      variables: {
        input: { title, author, description },
      }
      // optimisticResponse: ...,
      // update: ...,
    })
  }
})

Choose APOLLO

Building a client web application

You make more efficient requests from your server.



You write less boilerplate code.



You can easily improve perceived performance through caching and optimistic mutations.

Choose APOLLO

Building a client web application

Turn to the next section to find out.

Hopefully there are no bugs lurking around here though..

Choose Apollo

API Design for Client Side Caching

As your single page app grows, you may see more caching bugs..

query storiesForAuthor {
  author(id: "1") {
    id
    firstName
    lastName
    stories {
      id
      title
    }
  }
}
query listOfAuthors {
  authors {
     id
     firstName
     lastName
  }
}
mutation changeStory {
  updateStory(input:{
    id:"1",
    title: "Update this!"
  }) {
    story {
      id
      title
    }
  }
}

Choose Apollo

API Design for Client Side Caching

...we ensure that the cache will be updated properly.

As we add more queries and mutations, If all objects have a globally unique ID...

When removing items from lists...

Choose Apollo

API Design for Client Side Caching

query storiesForAuthors {
  author(id: "1") {
    id
    firstName
    lastName
    stories {
      id
      title
    }
  }
}
mutation removeStory {
  removeStory(input:{
    authorId:"1",
    storyId: "6"
  }) {
    story { # RETURNS REMOVED STORY DATA
      id
      title
    }
  }
}

...you may not see them properly removed on the page.

<Mutation
  mutation={REMOVE_STORY}
  update={(cache, { data: { removeStory } }) => {
    const { stories } = cache.readQuery({ query: GET_STORIES });
    cache.writeQuery({
      query: GET_STORIES,
      data: {
        stories: stories.filter(
          (stories) => story.id == removeStory.story.id
        ) },
    });
  }}
>
  ...

Choose Apollo

API Design for Client Side Caching

Apollo provides a mechanism for manually upating the cache...

...but this can be hard to reason about and test.

<Mutation
  mutation={REMOVE_STORY}
  refetchQueries={['allStories']}
>
  ...

Choose Apollo

API Design for Client Side Caching

We could also more simply just refetch any affected queries...

...but as your page grows, it can be hard to maintain a full list of queries and can be expensive to refetch!

query storiesForAuthors {
  author(id: "1") {
    id
    firstName
    lastName
    stories {
      id
      title
    }
  }
}
mutation removeStory {
  removeStory(input:{
    authorId:"1",
    storyId:"6"
  }) {
    story {
      id
      title
    }
    author {
      id
      stories {
        id
      }
    }
  }
}

Choose Apollo

API Design for Client Side Caching

...the cached list of stories for our author will be updated automatically!

If we design our mutation payload correctly..

query storiesForAuthors {
  author(id: "1") {
    id
    firstName
    lastName
    stories {
      id
      title
      description
    }
  }
}
mutation addPost {
  addPost(input:{
    authorId:"1",
    title: "Stuff"
  }) {
    post {
      id
      title

    }
    author {
      id
      stories {
        id
      }
    }
  }
}

Choose Apollo

API Design for Client Side Caching

When adding to a list with a mutation...

We'll face errors in Apollo due to missing fields in our new post.

query postsForAuthors {
  author(id: "1") {
    id
    firstName
    lastName
    story {
      ...allStoryFields
    }
  }
}

fragment allStoryFields on Story {
  id
  title
  description
}
mutation removePost {
  addStory(input:{
    authorId:"1",
    title: "Stuff"
  }) {
    story {
      ...allStoryFields
    }
    author {
      id
      stories {
        id
      }
    }
  }
}

Choose Apollo

API Design for Client Side Caching

Fragments can help us ensure that all fields are fetched when adding an item to a list.

The web application with GraphQL and Apollo is really coming together.

Everyone shares some cake and pie in the space break room to celebrate.

Mmm, mm.. Turn to the next section.

Choose APOLLO

Building a client web application

EPILOGUE TO Your Adventure

A parting word before the next adventure

It was long, hard work, but you built a robust web application and API backend.



GraphQL is useful as a general purpose API with productive frameworks for development.

But REST is still a proven and scalable solution.



Next time what will you choose?

Maybe you'll choose to build a REST API...

Or maybe you'll choose to build a flexible API with GraphQL!

The end

Thanks for listening!

Questions?

       @dvndrsn

The Rabbit Hole Podcast: http://bit.ly/2Jous2O

Stride Consulting: https://www.stridenyc.com/careers​

Joor: https://jooraccess.com/careers​

Dave Anderson

References

Thanks for listening!

Icons8 (open source icons):

https://icons8.com/



Open Clip Art:

https://openclipart.org/



Code Sample:

https://github.com/dvndrsn/cyoa-story



Graphene (Python):

http://docs.graphene-python.org/en/latest/



Apollo (JavaScript):

https://www.apollographql.com/docs/

GraphQL: A Choose Your Own Adventure for Client Web Services (PyGotham)

By dvndrsn

Made with Slides.com

GraphQL: A Choose Your Own Adventure for Client Web Services (PyGotham)

In the style of a modern, web-development choose your own adventure, we'll explore the benefits and trade offs of GraphQL and REST. We'll build up an example schema using a choose your own adventure story as the model and leverage that schema in frontend code. We'll also learn about some advanced considerations of GraphQL like performance and caching.

  • 2,067

More from dvndrsn

  • Building Evolutionary API with GraphQL and Python
    dvndrsn
    3202
  • Trunk Based Development: In a Nutshell (2U)
    dvndrsn
    1040
  • GraphQL, Apollo Caching and API Design!
    dvndrsn
    1023
  • Choose Your Own Adventure for Client Web Services with GraphQL
    dvndrsn
    1392
