Cognitive Computing

James L. Weaver
Developer Advocate



jweaver@pivotal.io
JavaFXpert.com

@JavaFXpert

Sandhya Kapoor
Senior Software Engineer




kapoor@us.ibm.com
ibm.co/2dHGB28

@SandhyaKapoor9

About Presenter James Weaver

Java Champion, JavaOne Rockstar, plays well with others, etc :-)

Author of several Java/JavaFX/RaspPi books

@JavaFXpert

Developer Advocate & International Speaker for Pivotal

About Presenter Sandhya Kapoor

Developer, Women in Tech Activist

Senior Systems Engineer & Cognitive Computing Advocate for IBM

@SandhyaKapoor

Holds seven computer science related patents

Added Java 2 Security to WebSphere

International Speaker

Workshop Prerequisites (1 of 2)

Prior to the workshop, attendees must have installed the following:

@JavaFXpert

Deeplearning4j deeplearning4j.org examples

- Follow the Quick Start Guide http://deeplearning4j.org/quickstart through and including the DL4J Examples in a Few Easy Steps section.

- Criterion for successful install is that running CSVExample yields output that ends with a block of scores similar to the following:

Workshop Prerequisites (2 of 2)

Prior to the workshop, attendees must have installed the following:

@JavaFXpert

BURLAP burlap.cs.brown.edu examples

Use a similar procedure to install the BURLAP examples from the GitHub repository https://github.com/jmacglashan/burlap_examples/ as you did installing the Deeplearning4j examples from its GitHub repository.  This procedure is:

> git clone https://github.com/jmacglashan/burlap_examples.git

> cd burlap_examples

> mvn clean install

Open the burlap_examples project in your IDE.

Criterion for successful installation is that running HelloGridWorld yields the display as shown on the right:

Workshop Part One

The labs follow this slide, but click here to see the content of Part One of this workshop.

Neural Network Lab:

@JavaFXpert

In CSVExample (located in the dl4j-examples project), modify the following hyperparameters and notice the effects on scores in the console ouput:

  • Learning rate
  • Iterations
  • Number of nodes in hidden layers
  • Number of hidden layers



Modifying Hyperparameters

Neural Network Lab:

@JavaFXpert

In CSVExample (located in the dl4j-examples project), add the following lines of code to classify/predict an Iris flower that doesn't exist in the Iris dataset:

Making predictions

INDArray example = Nd4j.zeros(1, 4);
example.putScalar(new int[] { 0, 0 }, 5.1);
example.putScalar(new int[] { 0, 1 }, 3.5);
example.putScalar(new int[] { 0, 2 }, 1.4);
example.putScalar(new int[] { 0, 3 }, 0.2);
DataSet ds = new DataSet(example, null);
normalizer.transform(ds);
int[] prediction = model.predict(example);
System.out.println("prediction for 5.1,3.5,1.4,0.2: " + prediction[0]);



Reinforcement Learning Lab:

@JavaFXpert

In BasicBehavior (located in the burlap_examples project), make the only uncommented lines in the main() method be the following:

Modifying the rewards

example.qLearningExample(outputPath);
example.visualize(outputPath);

In the BasicBehavior() constructor method, add the bolded lines between the existing lines shown below, and observe the effects on the values in the states of the grid world.

goalCondition = new TFGoalCondition(tf);
RewardFunction rf = new GoalBasedRF(tf, 5.0);
gwdg.setRf(rf);
domain = gwdg.generateDomain();

Reinforcement Learning Lab:

@JavaFXpert

In BasicBehavior (located in the burlap_examples project), verify that the only uncommented lines in the main() method are the following:

Modifying the Discount Factor

example.qLearningExample(outputPath);
example.visualize(outputPath);

In the qLearningExample() method, modify the gamma (discount factor) argument to the QLearning constructor and observe the effects on the values in the states of the grid world.
