Karl Ho
Data Generation datageneration.io
Karl Ho
School of Economic, Political and Policy Sciences
University of Texas at Dallas
Workshop prepared for International Society for Data Science and Analytics (ISDSA) Annual Meeting, Notre Dame University, June 2nd, 2022.
Principal Components Analysis (PCA) produces a low-dimensional representation of a dataset. It finds a sequence of linear combinations of the variables that have maximal variance, and are mutually uncorrelated.
Apart from producing derived variables for use in supervised learning problems, PCA also serves as a tool for data visualization.
The first principal component of a set of features
\(X_1, X_2, . . . , X_p\) is the normalized linear combination of the features:
that has the largest variance. By normalized, we mean that
\(\sum_{j=1}^p\phi_{j1}^2 = 1\).
The elements \(\phi_{11}, . . . , \phi_{p1}\) are the loadings of the first principal component; together, the loadings make up
the principal component loading vector, \(\phi_1 = (\phi_{11} \phi_{21} ... \phi_{p1})^T\) .
We constrain the loadings so that their sum of squares is equal to one, since otherwise setting these elements to be arbitrarily large in absolute value could result in an arbitrarily large variance.
\(Z_1 = \phi_{11}X_1 +\phi_{21}X_2 +...+\phi_{p1}X_p\)
The population size (pop) and ad spending (ad) for 100 different cities are shown as purple circles. The green solid line indicates the first principal component direction, and the blue dashed line indicates the second principal component directio
Suppose we have a \(n×p\) data set \(X\). Since we are only interested in variance, we assume that each of the variables in \(X\) has been centered to have mean zero (that is, the column means of \(X\)are zero).
We then look for the linear combination of the sample feature values of the form
for \(i = 1, . . . , n\) that has largest sample variance, subject to
the constraint that \(\sum^p_{j=1} \phi^2_{j1} = 1\).
Since each of the \(x_{ij}\) has mean zero, then so does \(z_{i1}\) (for any values of \(\phi_{j1}\)). Hence the sample variance of the \(z_{i1}\) can be written as \(\frac{1}{n}\sum^n_{i=1}z_{i1}^2\).
\(Z_{i1} = \phi_{11}X_{i1} +\phi_{21}X_{i2} +...+\phi_{p1}X_{ip}\)
(1)
Plugging in (1) the first principal component loading vector solves the optimization problem
This problem can be solved via a singular-value decomposition of the matrix \(X\), a standard technique in linear algebra.
We refer to \(Z_1\) as the first principal component, with realized values \(z_{11}, . . . , z_{n1}\)
The loading vector \(\phi_1\) with elements \(\phi_{11}, \phi_{21},...,\phi_{p1}\) defines a direction in feature space along which the data vary the most.
If we project the \(n\) data points \(x_1,...,x_n\) onto this direction, the projected values are the principal component scores \(z_{11},...,z_{n1}\) themselves.
The second principal component is the linear combination of \(X_1, . . . , X_p\) that has maximal variance among all linear combinations that are uncorrelated with \(Z_1\).
The second principal component scores \(z_{12}, z_{22},..., z_{n2}\) take the form:
\(z{i2} = \phi_{12}x_{i1} + \phi_{22}x_{i2} +...+ \phi_{p2}x_{ip}\),
where \(\phi_2\) is the second principal component loading vector, with elements \(\phi_{12}, \phi_{22}, . . . , \phi_{p2}\).
It turns out that constraining \(Z_2\) to be uncorrelated with \(Z_1\) is equivalent to constraining the direction \(\phi_2\) to be orthogonal (perpendicular) to the direction \(\phi_1\). And so on.
The principal component directions \(\phi_1\),\(\phi_2\), \(\phi_3\), . . . are the ordered sequence of right singular vectors of the matrix \(X\), and the variances of the components are \(\frac{1}{n}\) times the squares of the singular values. There are at most
\(min(n − 1, p)\) principal components.
The first two principal components for the USArrests data.
The black state names represent the scores for the first two principal components.
The red arrows indicate the first two principal component loading vectors (with axes on the top and right). For example, the loading for Rape on the first component is 0.54, and its loading on the second principal component 0.17 [the word Rape is centered at the point (0.54, 0.17)]. (Note scale difference in plot)
PC1 PC2 PC3 PC4 Murder -0.5358995 0.4181809 -0.3412327 0.64922780 Assault -0.5831836 0.1879856 -0.2681484 -0.74340748 UrbanPop -0.2781909 -0.8728062 -0.3780158 0.13387773 Rape -0.5434321 -0.1673186 0.8177779 0.08902432
The first principal component loading vector has a very special property: it defines the line in \(p\)-dimensional space that is closest to the \(n\) observations (using average squared Euclidean distance as a measure of closeness)
The notion of principal components as the dimensions that are closest to the \(n\) observations extends beyond just the first principal component.
For instance, the first two principal components of a data set span the plane that is closest to the \(n\) observations, in terms of average squared Euclidean distance.
We would like to partition that data set into K clusters:
The clusters are non-overlapping, i.e. no observation belongs to more than one cluster
The objective is to have a minimal “within-cluster-variation”, i.e. the elements within a cluster should be as similar as possible
One way of achieving this is to minimize the sum of all the pair-wise squared Euclidean distances between the observations in each cluster.
\(C_1,...,C_K\)
Step 1: random assignment of points to k groups
Iteration 1 Step 2a:
Compute cluster centroids
Iteration 1 Step 2b:
Assign points to closest cluster center
Iteration 2 Step 2a:
Compute new cluster centroids
Stop at k center points where there's no further change.
K-Means clustering requires choosing the number of clusters.
An alternative is Hierarchical Clustering which does not require that we commit to a particular choice of \(K\).
Hierarchical Clustering has an advantage that it produces a tree-based representation of the observations: Dendrogram
A dendrogram is built starting from the leaves and combining clusters up to the trunk.
First join closest points (5 and 7)
Height of fusing/merging (on vertical axis) indicates how similar the points are
After the points are fused they are treated as a single observation and the algorithm continues
Each “leaf” of the dendogram represents one of the 45 observations
At the bottom of the dendogram, each observation is a distinct leaf. However, as we move up the tree, some leaves begin to fuse. These correspond to observations that are similar to each other.
As we move higher up the tree, an increasing number of observations have fused. The earlier (lower in the tree) two observations fuse, the more similar they are to each other.
Observations that fuse later are quite different
To choose clusters we draw lines across the dendrogram
We can form any number of clusters depending on where we draw the break point.
One cluster
Two clusters
Three clusters
To build the dendrogram:
Start with each point as a separate cluster (\(n\) clusters)
Calculate a measure of dissimilarity between all points/clusters
Fuse two clusters that are most similar so that there are now \(n-1\) clusters
Fuse next two most similar clusters so there are now \(n-2\) clusters
Continue until there is only 1 cluster
Complete |
Maximal inter-cluster dissimilarity. Compute all pairwise dissimilarities between the observations in cluster A and the observations in cluster B, and record the largest of these dissimilarities. |
Single |
Minimal inter-cluster dissimilarity. Compute all pairwise dissimilarities between the observations in cluster A and the observations in cluster B, and record the smallest of these dissimilarities. |
Average |
Mean inter-cluster dissimilarity. Compute all pairwise dissimilarities between the observations in cluster A and the observations in cluster B, and record the average of these dissimilarities. |
Centroid |
Dissimilarity between the centroid for cluster A (a mean vector of length p) and the centroid for cluster B. Centroid linkage can result in undesirable inversions. |
We have considered using Euclidean distance as the dissimilarity measure
An alternative is correlation-based distance which considers
two observations to be similar if their features are highly
correlated.
This is an unusual use of correlation, which is normally
computed between variables; here it is computed between the observation profiles for each pair of observations.
We have considered using Euclidean distance as the dissimilarity measure
An alternative is correlation-based distance which considers
two observations to be similar if their features are highly
correlated.
This is an unusual use of correlation, which is normally
computed between variables; here it is computed between the observation profiles for each pair of observations.
In this example, we have 3 observations and p = 20 variables
In terms of Euclidean distance obs. 1 and 3 are similar. However, obs. 1 and 2 are highly correlated so would be considered similar in terms of correlation measure.
Suppose we record the number of purchases of each item (columns) for each customer (rows)
Using Euclidean distance, customers who have purchases very little will be clustered together
Using correlation measure, customers who tend to purchase the same types of products will be clustered together even if the magnitude of their purchase may be quite different
Consider an online shop that sells two items: socks and computers
Left: In terms of quantity, socks have higher weight
Center: After standardizing, socks and computers have equal weight
Right: In terms of dollar sales, computers have higher weight
Quantity
Price
Should the features first be standardized? i.e. Have the variables centered to have a mean of zero and standard deviation of one.
For K-means clustering,
How many clusters should be set?
For Hierarchical Clustering,
What dissimilarity measure should be used?
What type of linkage should be used?
Where should we cut the dendrogram in order to obtain clusters?
In real world research, try several different choices, and decide on one that is interpretable!
Unsupervised learning is important for understanding the variation and grouping structure of a set of unlabeled data, and can be a useful pre-processor for supervised learning
It is intrinsically more difficult than supervised learning because there is no gold standard (like an outcome variable) and no single objective (like test set accuracy).
It is an active field of research, with many recently developed tools such as self-organizing maps, independent components analysis and spectral clustering.
Deep learning is a neural-networks technique that organizes the neurons in many more than multi-layer perceptrons. It is in this sense the networks are “deep,” and this is what gave the paradigm its name.
