Supervised learning in R:
caret to streamline the model building process

Trang Lê

R Ladies Philly Meetup

December 2, 2019

slides.com/trang1618

bit.ly/33MFHLy

https://trang.page

@trang1618

0000-0003-3737-6565

postdoc with Jason Moore
author, maintainer
- npdr selects features with
  nearest-neighbor concepts
- stir reliefF on steroid
- privateEC differential privacy for machine learning
contributor
- tpot
amateur runner

On the topic of ML, there are many things to talk about...

challenges: missing data, outlier, bias, overfitting, colinearity, etc.
unsupervised learning
feature selection
```
R packages::recipes
```
(lots of) clean data
evaluation metrics
deep learning
automated machine learning
big data
terminology

adapted from Drew Conway’s Data Science Venn Diagram

hacking
skills

machine learning

math

statistics

domain knowledge

Danger zone!

data
science

traditional research

ML primers
Explore
Ask questions
Predict
Visualize

but for today...

Regression

outcome: continuous/quantitative

e.g. How sick is patient?

on a scale of 10

Classification

outcome: discrete/categorical/class

e.g. Is patient sick?

TRUE, FALSE

1, 0

Supervised learning==Predictive modeling

\textrm{argmin}_\beta (\|y- X\beta\|^2 + \lambda_1 \|\beta\|+ \lambda_2 \|\beta\|^2)

During training...

hyperparameters

parameters

We tune the model's hyperparameters.

As we fit the model to the data, model learns parameters from the data.

Hyperparameters

Parameters

e.g. Elastic net is a type of models

An Introduction to Statistical Learning, 2014

Supervised learning of tabular data

5 fold cross-validation

Data

Train

Test

Train

observation

sample

individual

subject

variable feature attribute

1. Define sets of model hyperparameters values

2. for each hyperparameter set:

3. for each resampling iteration:

4. Hold out specific samples

5. Fit model on training data

6. Predict the hold out samples

7. end

8. Average performance across hold out predictions

9. end

10. Find optimal hyperparameter set

11. Fit final model to all training data with
optimal parameter set

1. Define sets of model hyperparameters values

2. for each hyperparameter set:

3. for each resampling iteration:

4. Hold out specific samples

5. Fit model on training data

6. Predict the hold out samples

7. end

8. Average performance across hold out predictions

9. end

10. Find optimal hyperparameter set

11. Fit final model to all training data with
optimal parameter set

hyperparameter tuning

rf_fit <- train(
  price ~ .,
  data = Boston,
  method = 'randomForest',

  tuneGrid = expand.grid(
    mtry = 2:7,
    ntree = c(1000, 1500)
  ),
  trControl = trainControl('cv')
)

caret was developed to

create a unified interface for predictive modeling with 238 models
streamline model tuning using resampling
helper functions for day-to-day model building tasks
parallel processing for computational efficiency
enable several feature selection frameworks

Max Kuhn, useR-2010

https://topepo.github.io/caret/

RStudio primers

cmd/ctrl + enter execute line
cmd/ctrl + shift + enter execute chunk

h(g(f(x)))

x %>%

  f() %>%

  g() %>%

  h()

Let's start with an example!

beer/name: John Harvards Simcoe IPA
beer/ABV: 5.4
beer/style: India Pale Ale (IPA)
review/appearance: 4/5
review/aroma: 6/10
review/palate: 3/5
review/taste: 6/10
review/overall: 13/20
review/time: 1157587200
review/text: On tap at the Springfield, PA location. Poured a deep and cloudy orange (almost a copper) color with a small sized white head. Tastes of oranges, light caramel and a very light grapefruit finish. I too would not believe the 80+ IBUs - I found this one to have a very light bitterness with a medium sweetness to it. Light lacing left on the glass.
