Medicare Appointment Booking & Scheduling
Business Scenario
In this lab, we will enhance the Medicare application by implementing the appointment booking workflow for patients.
Pre-Lab Preparation
Module:
1) React Basics & Backend Integration (Spring Boot)
Phase 12E — Appointment Booking
- Now we connect:
Find Doctor ↓ Doctor Card ↓ Book Appointment ↓ Select Date
↓ Select Slot ↓ POST /api/appointments ↓ PENDING + UNPAID ↓ Booking Confirmation
- For now we stop at: PENDING / UNPAID because payment is still Phase 13.
Create appointmentService.js
1
- Create:
src/services/appointmentService.js
import api, {getAuthConfig} from "../api/api";
const createAppointment = async (appointmentData) => {
const response = await api.post("/appointments",appointmentData,
getAuthConfig());
return response.data;
};
const appointmentService = {createAppointment};
export default appointmentService;- For now only one function. We will add:
getMyAppointments() cancelAppointment() getDoctorAppointments() completeAppointment()
- In the next phase when those screens are implemented.
Update DoctorCard
2
- Currently the button is disabled.
- Open:src/components/doctor/DoctorCard.jsx
- Add:
import {Link} from "react-router";- Then replace:
<button className="btn btn-primary w-100" disabled>
Book Appointment
</button>- With :
<Link to={`/patient/doctors/${doctor.id}/book`} className="btn btn-primary w-100">
Book Appointment
</Link>- Your complete DoctorCard.jsx becomes:
import { Link } from "react-router";
function DoctorCard({ doctor }) {
return (
<div className="card h-100 shadow-sm">
{doctor.photoUrl ? (
<img
src={doctor.photoUrl}
className="card-img-top"
alt={doctor.name}
style={{ height: "220px", objectFit: "cover" }}
/> ) : (
<div
className="bg-light d-flex align-items-center j
ustify-content-center text-secondary"
style={{ height: "220px" }}>
No Photo
</div>
)}
<div className="card-body d-flex flex-column">
<h5 className="card-title">{doctor.name}</h5>
<p className="text-primary fw-semibold mb-2">
{doctor.specialization}
</p>
<p className="card-text mb-2">
<strong>Experience:</strong> {doctor.experienceYears} years
</p>
<p className="card-text mb-4">
<strong>Consultation Fee:</strong> ₹{doctor.consultationFee}
</p>
<Link
to={`/patient/doctors/${doctor.id}/book`}
className="btn btn-primary w-100 mt-auto"
>
Book Appointment
</Link> </div>
</div>
);
}
export default DoctorCard;Create Booking Page
3
- Create:
src/pages/patient/BookAppointment.jsx
- Use :
import { useEffect, useState } from "react";
import { Link, useParams } from "react-router";
import doctorService from "../../services/doctorService";
import appointmentService from "../../services/appointmentService";
function BookAppointment() {
const { doctorId } = useParams();
const [doctor, setDoctor] = useState(null);
const [appointmentDate, setAppointmentDate] = useState("");
const [timeSlot, setTimeSlot] = useState("");
const [loadingDoctor, setLoadingDoctor] = useState(true);
const [booking, setBooking] = useState(false);
const [error, setError] = useState("");
const [success, setSuccess] = useState(null);
useEffect(() => {
loadDoctor();
}, [doctorId]);
const loadDoctor = async () => {
try {
setLoadingDoctor(true);
setError("");
const data = await doctorService.getDoctorById(doctorId);
setDoctor(data);
} catch (error) {
setError(error.response?.data?.message ||
"Unable to load doctor");
} finally {
setLoadingDoctor(false);
}
};
const getToday = () => {
const today = new Date();
const year = today.getFullYear();
const month = String(today.getMonth() + 1).padStart(2, "0");
const day = String(today.getDate()).padStart(2, "0");
return `${year}-${month}-${day}`;
};
const handleSubmit = async (event) => {
event.preventDefault();
setError("");
setSuccess(null);
if (!appointmentDate) {
setError("Please select an appointment date");
return;
}
if (!timeSlot) {
setError("Please select a time slot");
return;
}
try {
setBooking(true);
const appointmentData = {
doctorId: Number(doctorId),
appointmentDate,
timeSlot
};
const response =
await appointmentService.createAppointment(appointmentData);
setSuccess(response);
setAppointmentDate("");
setTimeSlot("");
} catch (error) {
setError(error.response?.data?.message ||
"Unable to book appointment");
} finally {
setBooking(false);
}
};
if (loadingDoctor) {
return (
<div className="container py-5 text-center">
<div className="spinner-border text-primary"></div>
<p className="text-secondary mt-3">Loading doctor...</p>
</div>
);
}
if (!doctor) {
return (
<div className="container py-5">
<div className="alert alert-danger">
Doctor information could not be loaded.
</div>
<Link to="/patient/doctors" className="btn btn-primary">
Back to Doctors
</Link>
</div>
);
}
return (
<div className="container py-5">
<div className="row justify-content-center">
<div className="col-lg-8">
{/* PAGE HEADER */}
<div className="mb-4">
<h2>Book Appointment</h2>
<p className="text-secondary">
Select your preferred appointment date and time.
</p>
</div>
{/* DOCTOR INFORMATION */}
<div className="card shadow-sm mb-4">
<div className="card-body">
<div className="row align-items-center">
{doctor.photoUrl && (
<div className="col-md-3 mb-3 mb-md-0">
<img src={doctor.photoUrl} alt={doctor.name}
className="img-fluid rounded" />
</div>
)}
<div className={doctor.photoUrl ? "col-md-9" : "col-12"}>
<h4 className="mb-1">{doctor.name}</h4>
<p className="text-primary fw-semibold mb-2">
{doctor.specialization}
</p>
<p className="mb-1">
<strong>Experience:</strong>
{doctor.experienceYears} years
</p>
<p className="mb-0">
<strong>Consultation Fee:</strong>
₹{doctor.consultationFee}
</p>
</div>
</div>
</div>
</div>
{/* ERROR */}
{error && (
<div className="alert alert-danger">{error}</div>
)}
{/* SUCCESS */}
{success && (
<div className="alert alert-success">
<h5>Appointment Booked</h5>
<p className="mb-1">
Appointment ID: <strong>{success.id}</strong>
</p>
<p className="mb-1">
Doctor: <strong>{success.doctorName}</strong>
</p>
<p className="mb-1">
Date: <strong>{success.appointmentDate}</strong>
</p>
<p className="mb-1">
Slot: <strong>{success.timeSlot}</strong>
</p>
<p className="mb-1">
Status: <strong>{success.appointmentStatus}</strong>
</p>
<p className="mb-0">
Payment: <strong>{success.paymentStatus}</strong>
</p>
</div>
)}
{/* BOOKING FORM */}
<div className="card shadow-sm">
<div className="card-body p-4">
<form onSubmit={handleSubmit}>
{/* DATE */}
<div className="mb-4">
<label className="form-label">
Appointment Date</label>
<input
type="date"
className="form-control"
min={getToday()}
value={appointmentDate}
onChange={(event) =>
setAppointmentDate(event.target.value)}
required
/>
</div>
{/* TIME SLOT */}
<div className="mb-4">
<label className="form-label">
Select Time Slot</label>
<div className="row g-3">
{/* 10 AM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotMorning"
value="MORNING_10_AM"
checked={timeSlot === "MORNING_10_AM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary w-100"
htmlFor="slotMorning">
10:00 AM
</label>
</div>
{/* 2 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotAfternoon"
value="AFTERNOON_2_PM"
checked={timeSlot === "AFTERNOON_2_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotAfternoon">
2:00 PM
</label>
</div>
{/* 5 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotEvening"
value="EVENING_5_PM"
checked={timeSlot === "EVENING_5_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotEvening">
5:00 PM
</label>
</div>
</div>
</div>
{/* FEE */}
<div className="alert alert-light border">
Consultation Fee: <strong>
₹{doctor.consultationFee}</strong>
</div>
<div className="d-flex gap-2">
<Link to="/patient/doctors"
className="btn btn-outline-secondary">
Back
</Link>
<button
type="submit"
className="btn btn-primary flex-grow-1"
disabled={booking}
>
{booking ? "Booking..." : "Book Appointment"}
</button>
</div>
</form>
</div>
</div>
</div>
</div>
</div>
);
}
export default BookAppointment;
function BookAppointment() {
const { doctorId } = useParams();
const [doctor, setDoctor] = useState(null);
const [appointmentDate, setAppointmentDate] = useState("");
const [timeSlot, setTimeSlot] = useState("");
const [loadingDoctor, setLoadingDoctor] = useState(true);
const [booking, setBooking] = useState(false);
const [error, setError] = useState("");
const [success, setSuccess] = useState(null);
useEffect(() => {
loadDoctor();
}, [doctorId]);
const loadDoctor = async () => {
try {
setLoadingDoctor(true);
setError("");
const data = await doctorService.getDoctorById(doctorId);
setDoctor(data);
} catch (error) {
setError(error.response?.data?.message ||
"Unable to load doctor");
} finally {
setLoadingDoctor(false);
}
};
const getToday = () => {
const today = new Date();
const year = today.getFullYear();
const month = String(today.getMonth() + 1).padStart(2, "0");
const day = String(today.getDate()).padStart(2, "0");
return `${year}-${month}-${day}`;
};
const handleSubmit = async (event) => {
event.preventDefault();
setError("");
setSuccess(null);
if (!appointmentDate) {
setError("Please select an appointment date");
return;
}
if (!timeSlot) {
setError("Please select a time slot");
return;
}
try {
setBooking(true);
const appointmentData = {
doctorId: Number(doctorId),
appointmentDate,
timeSlot
};
const response =
await appointmentService.createAppointment(appointmentData);
setSuccess(response);
setAppointmentDate("");
setTimeSlot("");
} catch (error) {
setError(error.response?.data?.message ||
"Unable to book appointment");
} finally {
setBooking(false);
}
};
if (loadingDoctor) {
return (
<div className="container py-5 text-center">
<div className="spinner-border text-primary"></div>
<p className="text-secondary mt-3">Loading doctor...</p>
</div>
);
}
if (!doctor) {
return (
<div className="container py-5">
<div className="alert alert-danger">
Doctor information could not be loaded.
</div>
<Link to="/patient/doctors" className="btn btn-primary">
Back to Doctors
</Link>
</div>
);
}
return (
<div className="container py-5">
<div className="row justify-content-center">
<div className="col-lg-8">
{/* PAGE HEADER */}
<div className="mb-4">
<h2>Book Appointment</h2>
<p className="text-secondary">
Select your preferred appointment date and time.
</p>
</div>
{/* DOCTOR INFORMATION */}
<div className="card shadow-sm mb-4">
<div className="card-body">
<div className="row align-items-center">
{doctor.photoUrl && (
<div className="col-md-3 mb-3 mb-md-0">
<img src={doctor.photoUrl} alt={doctor.name}
className="img-fluid rounded" />
</div>
)}
<div className={doctor.photoUrl ? "col-md-9" : "col-12"}>
<h4 className="mb-1">{doctor.name}</h4>
<p className="text-primary fw-semibold mb-2">
{doctor.specialization}
</p>
<p className="mb-1">
<strong>Experience:</strong>
{doctor.experienceYears} years
</p>
<p className="mb-0">
<strong>Consultation Fee:</strong>
₹{doctor.consultationFee}
</p>
</div>
</div>
</div>
</div>
{/* ERROR */}
{error && (
<div className="alert alert-danger">{error}</div>
)}
{/* SUCCESS */}
{success && (
<div className="alert alert-success">
<h5>Appointment Booked</h5>
<p className="mb-1">
Appointment ID: <strong>{success.id}</strong>
</p>
<p className="mb-1">
Doctor: <strong>{success.doctorName}</strong>
</p>
<p className="mb-1">
Date: <strong>{success.appointmentDate}</strong>
</p>
<p className="mb-1">
Slot: <strong>{success.timeSlot}</strong>
</p>
<p className="mb-1">
Status: <strong>{success.appointmentStatus}</strong>
</p>
<p className="mb-0">
Payment: <strong>{success.paymentStatus}</strong>
</p>
</div>
)}
{/* BOOKING FORM */}
<div className="card shadow-sm">
<div className="card-body p-4">
<form onSubmit={handleSubmit}>
{/* DATE */}
<div className="mb-4">
<label className="form-label">
Appointment Date</label>
<input
type="date"
className="form-control"
min={getToday()}
value={appointmentDate}
onChange={(event) =>
setAppointmentDate(event.target.value)}
required
/>
</div>
{/* TIME SLOT */}
<div className="mb-4">
<label className="form-label">
Select Time Slot</label>
<div className="row g-3">
{/* 10 AM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotMorning"
value="MORNING_10_AM"
checked={timeSlot === "MORNING_10_AM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary w-100"
htmlFor="slotMorning">
10:00 AM
</label>
</div>
{/* 2 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotAfternoon"
value="AFTERNOON_2_PM"
checked={timeSlot === "AFTERNOON_2_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotAfternoon">
2:00 PM
</label>
</div>
{/* 5 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotEvening"
value="EVENING_5_PM"
checked={timeSlot === "EVENING_5_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotEvening">
5:00 PM
</label>
</div>
</div>
</div>
{/* FEE */}
<div className="alert alert-light border">
Consultation Fee: <strong>
₹{doctor.consultationFee}</strong>
</div>
<div className="d-flex gap-2">
<Link to="/patient/doctors"
className="btn btn-outline-secondary">
Back
</Link>
<button
type="submit"
className="btn btn-primary flex-grow-1"
disabled={booking}
>
{booking ? "Booking..." : "Book Appointment"}
</button>
</div>
</form>
</div>
</div>
</div>
</div>
</div>
);
}
export default BookAppointment;
const getToday = () => {
const today = new Date();
const year = today.getFullYear();
const month = String(today.getMonth() + 1).padStart(2, "0");
const day = String(today.getDate()).padStart(2, "0");
return `${year}-${month}-${day}`;
};
const handleSubmit = async (event) => {
event.preventDefault();
setError("");
setSuccess(null);
if (!appointmentDate) {
setError("Please select an appointment date");
return;
}
if (!timeSlot) {
setError("Please select a time slot");
return;
}
try {
setBooking(true);
const appointmentData = {
doctorId: Number(doctorId),appointmentDate,timeSlot
};
const response =
await appointmentService.createAppointment(appointmentData);
setSuccess(response);
setAppointmentDate("");
setTimeSlot("");
} catch (error) {
setError(error.response?.data?.message ||
"Unable to book appointment");
} finally {
setBooking(false);
}
};
if (loadingDoctor) {
return (
<div className="container py-5 text-center">
<div className="spinner-border text-primary"></div>
<p className="text-secondary mt-3">Loading doctor...</p>
</div>
);
}
if (!doctor) {
return (
<div className="container py-5">
<div className="alert alert-danger">
Doctor information could not be loaded.
</div>
<Link to="/patient/doctors" className="btn btn-primary">
Back to Doctors
</Link>
</div>
);
}
return (
<div className="container py-5">
<div className="row justify-content-center">
<div className="col-lg-8">
{/* PAGE HEADER */}
<div className="mb-4">
<h2>Book Appointment</h2>
<p className="text-secondary">
Select your preferred appointment date and time.
</p>
</div>
{/* DOCTOR INFORMATION */}
<div className="card shadow-sm mb-4">
<div className="card-body">
<div className="row align-items-center">
{doctor.photoUrl && (
<div className="col-md-3 mb-3 mb-md-0">
<img src={doctor.photoUrl} alt={doctor.name}
className="img-fluid rounded" />
</div>
)}
<div className={doctor.photoUrl ? "col-md-9" : "col-12"}>
<h4 className="mb-1">{doctor.name}</h4>
<p className="text-primary fw-semibold mb-2">
{doctor.specialization}
</p>
<p className="mb-1">
<strong>Experience:</strong>
{doctor.experienceYears} years
</p>
<p className="mb-0">
<strong>Consultation Fee:</strong>
₹{doctor.consultationFee}
</p>
</div>
</div>
</div>
</div>
{/* ERROR */}
{error && (
<div className="alert alert-danger">{error}</div>
)}
{/* SUCCESS */}
{success && (
<div className="alert alert-success">
<h5>Appointment Booked</h5>
<p className="mb-1">
Appointment ID: <strong>{success.id}</strong>
</p>
<p className="mb-1">
Doctor: <strong>{success.doctorName}</strong>
</p>
<p className="mb-1">
Date: <strong>{success.appointmentDate}</strong>
</p>
<p className="mb-1">
Slot: <strong>{success.timeSlot}</strong>
</p>
<p className="mb-1">
Status: <strong>{success.appointmentStatus}</strong>
</p>
<p className="mb-0">
Payment: <strong>{success.paymentStatus}</strong>
</p>
</div>
)}
{/* BOOKING FORM */}
<div className="card shadow-sm">
<div className="card-body p-4">
<form onSubmit={handleSubmit}>
{/* DATE */}
<div className="mb-4">
<label className="form-label">
Appointment Date</label>
<input
type="date"
className="form-control"
min={getToday()}
value={appointmentDate}
onChange={(event) =>
setAppointmentDate(event.target.value)}
required
/>
</div>
{/* TIME SLOT */}
<div className="mb-4">
<label className="form-label">
Select Time Slot</label>
<div className="row g-3">
{/* 10 AM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotMorning"
value="MORNING_10_AM"
checked={timeSlot === "MORNING_10_AM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary w-100"
htmlFor="slotMorning">
10:00 AM
</label>
</div>
{/* 2 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotAfternoon"
value="AFTERNOON_2_PM"
checked={timeSlot === "AFTERNOON_2_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotAfternoon">
2:00 PM
</label>
</div>
{/* 5 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotEvening"
value="EVENING_5_PM"
checked={timeSlot === "EVENING_5_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotEvening">
5:00 PM
</label>
</div>
</div>
</div>
{/* FEE */}
<div className="alert alert-light border">
Consultation Fee: <strong>
₹{doctor.consultationFee}</strong>
</div>
<div className="d-flex gap-2">
<Link to="/patient/doctors"
className="btn btn-outline-secondary">
Back
</Link>
<button
type="submit"
className="btn btn-primary flex-grow-1"
disabled={booking}
>
{booking ? "Booking..." : "Book Appointment"}
</button>
</div>
</form>
</div>
</div>
</div>
</div>
</div>
);
}
export default BookAppointment;
const response =
await appointmentService.createAppointment(appointmentData);
setSuccess(response);
setAppointmentDate("");
setTimeSlot("");
} catch (error) {
setError(error.response?.data?.message ||
"Unable to book appointment");
} finally {
setBooking(false);
}
};
if (loadingDoctor) {
return (
<div className="container py-5 text-center">
<div className="spinner-border text-primary"></div>
<p className="text-secondary mt-3">Loading doctor...</p>
</div>
);
}
if (!doctor) {
return (
<div className="container py-5">
<div className="alert alert-danger">
Doctor information could not be loaded.
</div>
<Link to="/patient/doctors" className="btn btn-primary">
Back to Doctors
</Link>
</div>
);
}
return (
<div className="container py-5">
<div className="row justify-content-center">
<div className="col-lg-8">
{/* PAGE HEADER */}
<div className="mb-4">
<h2>Book Appointment</h2>
<p className="text-secondary">
Select your preferred appointment date and time.
</p>
</div>
{/* DOCTOR INFORMATION */}
<div className="card shadow-sm mb-4">
<div className="card-body">
<div className="row align-items-center">
{doctor.photoUrl && (
<div className="col-md-3 mb-3 mb-md-0">
<img src={doctor.photoUrl} alt={doctor.name}
className="img-fluid rounded" />
</div>
)}
<div className={doctor.photoUrl ?
"col-md-9" : "col-12"}>
<h4 className="mb-1">
{doctor.name}</h4>
<p className="text-primary
fw-semibold mb-2">
{doctor.specialization}
</p>
<p className="mb-1">
<strong>Experience:</strong>
{doctor.experienceYears} years
</p>
<p className="mb-0">
<strong>
Consultation Fee:</strong>
₹{doctor.consultationFee}
</p>
</div>
</div>
</div>
</div>
{/* ERROR */}
{error && (
<div className="alert alert-danger">
{error}</div>
)}
{/* SUCCESS */}
{success && (
<div className="alert alert-success">
<h5>Appointment Booked</h5>
<p className="mb-1">
Appointment ID: <strong>
{success.id}</strong>
</p>
<p className="mb-1">
Doctor: <strong>{success.doctorName}</strong>
</p>
<p className="mb-1">
Date: <strong>{success.appointmentDate}</strong>
</p>
<p className="mb-1">
Slot: <strong>{success.timeSlot}</strong>
</p>
<p className="mb-1">
Status: <strong>{success.appointmentStatus}</strong>
</p>
<p className="mb-0">
Payment: <strong>{success.paymentStatus}</strong>
</p>
</div>
)}
{/* BOOKING FORM */}
<div className="card shadow-sm">
<div className="card-body p-4">
<form onSubmit={handleSubmit}>
{/* DATE */}
<div className="mb-4">
<label className="form-label">
Appointment Date</label>
<input
type="date"
className="form-control"
min={getToday()}
value={appointmentDate}
onChange={(event) =>
setAppointmentDate(event.target.value)}
required
/>
</div>
{/* TIME SLOT */}
<div className="mb-4">
<label className="form-label">
Select Time Slot</label>
<div className="row g-3">
{/* 10 AM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotMorning"
value="MORNING_10_AM"
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label
className="btn btn-outline-primary w-100"
htmlFor="slotMorning">
10:00 AM
</label>
</div>
{/* 2 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotAfternoon"
value="AFTERNOON_2_PM"
checked={timeSlot === "AFTERNOON_2_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotAfternoon">
2:00 PM
</label>
</div>
{/* 5 PM */}
<div className="col-md-4">
<input
type="radio"
className="btn-check"
name="timeSlot"
id="slotEvening"
value="EVENING_5_PM"
checked={timeSlot === "EVENING_5_PM"}
onChange={(event) =>
setTimeSlot(event.target.value)}
/>
<label className="btn btn-outline-primary
w-100" htmlFor="slotEvening">
5:00 PM
</label>
</div>
</div>
</div>
{/* FEE */}
<div className="alert alert-light border">
Consultation Fee: <strong>
₹{doctor.consultationFee}</strong>
</div>
<div className="d-flex gap-2">
<Link to="/patient/doctors"
className="btn btn-outline-secondary">
Back
</Link>
<button
type="submit"
className="btn btn-primary flex-grow-1"
disabled={booking}>
{booking ? "Booking..." : "Book Appointment"}
</button>
</div>
</form>
</div>
</div>
</div>
</div>
</div>
);
}
export default BookAppointment;Text
- The complete code file attached below contains the same code as provided above, with proper indentation and formatting for better readability.
Why the Backend Receives Enum Values
- The user sees:
10:00 AM 2:00 PM 5:00 PM
- But React sends:
MORNING_10_AM AFTERNOON_2_PM EVENING_5_PM
- Because our Spring enum is:
public enum TimeSlot {
MORNING_10_AM,
AFTERNOON_2_PM,
EVENING_5_PM
}- So:
Human-friendly UI ↓ Enum value ↓ Spring Boot
- This is better than exposing ugly enum names to the user.
Why We Don't Send Patient ID
- Our request becomes:
{
"doctorId": 3,
"appointmentDate": "2026-09-26",
"timeSlot": "MORNING_10_AM"
}- Notice :
patientId ❌ consultationFee ❌ appointmentStatus ❌ paymentStatus ❌
- The backend gets the patient from:
JWT ↓ email ↓ User
- And consultation fee from: DoctorProfile
Update Router
4
- Open src/routes/router.jsx
- Add:
import BookAppointment from "../pages/patient/BookAppointment";- Then inside MainLayout → children, add:
{
path: "patient/doctors/:doctorId/book",
element: (
<ProtectedRoute allowedRoles={[
"PATIENT"
]} >
<BookAppointment />
</ProtectedRoute>
)
},- So now: /patient/doctors contains doctor cards.
- Clicking doctor 3 goes to: /patient/doctors/3/book
- And: useParams() extracts: doctorId = "3"
Test Doctor Navigation
5
- Login as PATIENT.
Doctor Name Specialization Experience Fee
- Open: /patient/doctors
- Click: Book Appointment
- Suppose doctor ID is 3.
- You should reach: /patient/doctors/3/book
- The frontend calls: GET /api/doctors/3 and displays:
Test Appointment Booking
6
Date: September 26 Slot: 10:00 AM
- Select:
- Frontend sends:
POST /api/appointments Authorization: Bearer <patient-token> Content-Type: application/json
- Body:
{
"doctorId": 3,
"appointmentDate": "2026-09-26",
"timeSlot": "MORNING_10_AM"
}patient → from JWT doctor → ID 3 consultationFee → DoctorProfile appointmentStatus → PENDING paymentStatus → UNPAID
- Backend should create:
- Expected: 201 CREATED
- Expected Response
{
"id": 7,
"patientId": 1,
"patientName": "Rahul Shah",
"doctorId": 3,
"doctorName": "Dr. Ananya Sharma", "specialization": "Cardiologist", "appointmentDate": "2026-09-26", "timeSlot": "MORNING_10_AM", "consultationFee": 1200, "appointmentStatus": "PENDING", "paymentStatus": "UNPAID", "createdAt": "2026-09-24T18:10:00" }
Duplicate Slot Test
7
- Suppose this already exists:
Doctor: Dr. Ananya
Date: 2026-09-26
Slot: 10 AM- Try booking it again.
Doctor 3 + 2026-09-26 + MORNING_10_AM
- Backend should detect:
- And return: 409 CONFLICT
- Something like: Selected appointment slot is already booked
Test Another Slot
8
- Same doctor: September 26 but choose: 2:00 PM
{
"doctorId": 3,
"appointmentDate": "2026-09-26",
"timeSlot": "AFTERNOON_2_PM"
}- Request:
- This should succeed if that slot is free.
Test Another Doctor
9
- If: Dr. Ananya 10 AM is already booked, another doctor can still have:
Dr. Ananya 10 AM
Cancelled Slot Behavior
11
- Because slot availability is based on:
Doctor + Date + Slot
- Not globally across the hospital
- Our backend query intentionally ignores: CANCELLED appointments when checking
slot occupancy
- So:
Appointment Doctor 3 10 AM CANCELLED
- Means the same slot becomes available again.
We are done with this lab. The latest source code has been uploaded to GitHub. You can access the latest commit using the link below:
Great job!
You have successfully completed the appointment booking functionality in the Medicare application.
Checkpoint
Git Push
git push origin branchNameNext-Lab Preparation
Module:
1) React Basics & Backend Integration (Spring Boot)
SpringBoot Lab - 17
By Content ITV
