3D software developer at xeolabs.com

Lindsay Kay

WebGL Meetup, 18 November, 2020

xeokit

Web Programming Toolkit

a

for

Graphics

&

BIM

Engineering

1. What is BIM?

  • Building Information Modeling
  • Use models to collaborate on planning, design, construction and maintenance
  • Digitized construction management
  • Centered around a meta model, provided by the Industry Foundation Classes (IFC)

2. WebGL BIM Challenges

  • Load large models quickly
  • Navigate precisely, in both open and tight spaces
  • Fit large models in browser memory
  • Draw many objects, interactively
  • Accurately render full-precision geometry

3. What is xeokit?

  • A JavaScript SDK for developing model viewers for BIM and engineering
  • Uses WebGL (1)
  • Loads and views big models, at full-precision
  • Loads IFC, glTF, OBJ, STL, 3DXML, XKT & metadata to classify objects
  • Convert models with open source tools & host them on your own server
const viewer = new Viewer({
   canvasId: "myCanvas"
});

viewer.camera.eye = [0,0,10];
viewer.camera.look = [0,0,0];
viewer.camera.up = [-0, 1, 0];

const xktLoader =
      new XKTLoaderPlugin(viewer);

const model = xktLoader.load({
    src: "myModel.xkt",
    metaModelSrc: "myModel.json"
});

5. Loading Big Models Quickly

  • xeokit has a native, binary geometry format called "XKT"
  • Quantized, tiled  RTC vertex positions & oct-encoded normals
  • 48 bits per position, 16 bits per normal
  • Pre-computed wireframe indices
  • Convert IFC to XKT using open source CLI tools

6. Converting IFC Models for xeokit

Metadata

Geometry

7. Loading IFC Models into xeokit

import {Viewer} from "../src/viewer/Viewer.js";
import {XKTLoaderPlugin} from
"../src/plugins/XKTLoaderPlugin/XKTLoaderPlugin.js";

const viewer = new Viewer({
   canvasId: "myCanvas"
});

viewer.camera.eye = [1842022, 10, -5173301];
viewer.camera.look = [1842022, 10, -5173401];
viewer.camera.up = [-0.0, 1.0, 0.0];

const xktLoader = new XKTLoaderPlugin(viewer);

const model = xktLoader.load({
    metaModelSrc: "metadata.json",
    src: "geometry.xkt"
});

Minimal example

8. Minimizing Memory Footprint

  • xeokit stores geometry on the GPU, not in browser
  • Quantized RTC vertex positions, oct-encoded normals
  • 48 bits per double-precision position, 16 bits per normal

A large plumbing model at BIMData.io

9. Drawing Many Objects Interactively

1. ANGLE_instanced_arrays

xeokit uses two rendering techniques:

2. Batched Geometry Arrays

  • Combine single-use geometries into a single set of VBOs
  • Add an array of per-vertex flags, to hold object states
  • Vertex shader "discards" vertex when visible flag false
  • Update all vertex flags for an object to set its visibility

10. Accurate Rendering - Rounding Jitter on WebGL

  • GPUs are usually only single-precision, however
  • Many BIM models use double-precision coordinates
  • Need to emulate double-precision rendering to eliminate rounding jitter

Model centered at (1842022, 10, -5173301), provided by BIMData.io

11. Accurate Rendering - Eliminating Rounding Jitter

  • Coords are 32-bit offsets from their 64-bit tile centers, rendered using modified view matrix
  • Tiled, relative-to-center (RTC) coordinates

Read about RTC coordinates in virtualglobebook.com

  • Memory bonus: full-precision without the cost of storing double-precision values

12. Navigating Precisely

  • Distance-proportional rate of forward/backward movement
  • Ray-cast every n frames to find distance to nearest object, scale dolly and zoom rates accordingly

  • Move fast in open spaces, move slow in tighter spaces

13. xeokit in the Wild : OpenProject GmbH

  • View multiple models
  • Share issues via BCF
  • Slice, highlight, X-ray
  • Plan views

Thanks!
