Why use RabbitMQ?

  • Serves as a good messaging backend to
    do PUB/SUB etc in our middleware

  • Very robust
  • Can be configured to use persistent messages
  • Easy to use
  • Has bindings for every major language
  • Open Source
  • Lots of plugins
  • Widely used
  • Good documentation
  • Lots of tutorials

Usage

  1. Install the backend on a server
  2. Connect to it using your language of choice
  3. Define exchanges and their policies directly in code
  4. Send messages


Common Usage Patterns

Simple Messaging

Simply used to decouple components

A producer P produces messages,
while the consumer C consumes then

At-most-once semantics with persistent queues
At-least-once semantics if acknowledgements are used

Work Queues


Multiple consumers sharing workloads,
typically in a round-robin fashion

Messages can either be prefetched by workers
or delivered whenever a worker is available

Pub/Sub


Here the exchange X handles message delivery
As in the typical case, fanout delivery is used

Queues are generated for consumers, where their
relevant messages will then be sent

Routing

(Pub/sub + topics)
If multiple consumers listen to the same topic
then fanout-delivery is used

Hierarchical topics can also be used:
fridge.context.*
*.*.error
meetingroom.projector
meetingroom.*

RPC (Req/Rep)


Requests and replies are matched using correlation IDs
The client also specifies where the server should send the reply

Summary

  • Provides robust messaging
  • Lots of usage patterns
  • All language bindings we would want
  • Expansion opportunities

Questions?
