How SVG can save your day

Fronteers - 26 June 2022

Louis Hoebregts

@Mamboleoo

  • Front-end developer (Emakina, Base Design, Freelance)
  • Teacher of Generative Design & Web optimization, Namur
  • Coach for Hack Your Future, Brussels
  • Author on CSS-Tricks, Codrops, Generative Hut

What are SVGs?

  • Scalable Vector Graphics
  • Vector vs Bitmap
  • Markup language based on XML
  • Used to display icons, logos, maps, charts, illustrations
  • Can be interactive
  • Can be modified in CSS
  • Allows accessibility
<svg xmlns="http://www.w3.org/2000/svg" viewBox="0 0 100 100">
  <circle cx="30" cy="30" r="10" fill="lightblue" />
  <circle cx="70" cy="30" r="10" fill="lightblue" />
  <polyline stroke="coral" stroke-width="4" fill="none" points="20,60 40,80 60,80 80,60 "/>
</svg>

Read more

<svg aria-labelledby="titleID descID" role="img" viewBox="0 0 720 800">
  <title id="titleID">Topographic map of Belgium</title>
  <desc id="descID">A map of Belgium showing relief and contour lines.</desc>
  ...
</svg>

How to use them?

<img>

<img src="banana.svg" width="500" height="500" />

CSS background

.el{
    background-image: url(path/to/banana.svg);
}

Inline

<body>
  <svg viewBox="0 0 20 20">
    <rect x="0" y="0" width="10" height="10" />
  </svg>
</body>
document.querySelector('.dot').addEventListener('click', () => {
  alert('Congratulations, you clicked on a circle!');
});

scripts.js

.dot {
  fill: #BADA55;
  stroke: #c0ffee;
  stroke-width: 4px;
}

styles.css

When included in your HTML

<svg viewBox="0 0 50 50">
  <circle cx="25" cy="25" r="15" />
</svg>

index.html

<svg viewBox="0 0 50 50" xmlns="http://www.w3.org/2000/svg">
  <circle cx="25" cy="25" r="15" />
</svg>
<svg viewBox="0 0 50 50">
  <circle cx="25" cy="25" r="15" class="dot" />
</svg>
ul {
}
<ul>
  <li>Iron Man</li>
  <li>Superman</li>
  <li>Hulk</li>
</ul>

Using Data-uri

SASS Mixin to the rescue!

Demo

Pro

  • Library of icons available in CSS
  • Easier to update an icon for all pages
  • Code cached
  • Easily editable
  • Do not pollute your HTML

Cons

  • Icons cannot be animated
  • Increase your CSS file size

Clean your SVGs

https://jakearchibald.github.io/svgomg/

Animations

SMIL

Demo

CSS

Demo

JavaScript

Demo

⚠️ Transform-origin ⚠️

Demo

Gif-like images

Demo

Animated favicon

<svg viewBox="-5 -5 10 10" width="10" height="10" xmlns="http://www.w3.org/2000/svg" >
  <style>
    circle {
      animation: bounce 2s infinite ease-in-out alternate;
    }
    @keyframes bounce {
      to {
        transform: scale(0);
      }
    }
  </style>
  <circle r="5" />
</svg>

Demo

Firefox only 😢

CSS Media Queries

Demo

Dark mode

Demo

Prefers reduced motion

Demo

viewBox

<svg viewBox="min-x min-y width height">

Animating the viewBox

Demo

Using viewBox with an image

Demo

overflow: visible;

Demo

Vector-effect

Demo

Line animations

See online

stroke-dashoffset

Demo

document.querySelector('path').getTotalLength();

SVG Filters

See online

Duotone

Demo

Pencil effect

See online

Turbulence

See online

Line wrapping text

<foreignObject>

<svg viewBox="0 0 200 200">
  <foreignObject x="20" y="20" width="160" height="160">
    <p>
      Lorem ipsum dolor sit amet, consectetur adipiscing elit.
      Sed mollis mollis mi ut ultricies. Nullam magna ipsum,
      porta vel dui convallis, rutrum imperdiet eros. Aliquam
      erat volutpat.
    </p>
  </foreignObject>
</svg>

Docs

Automatic line wrapping

Demo

Illustrations © Vegetables - Dialog balloon - Clouds

Thank you ✨

https://mamboleoo.be/

@Mamboleoo

How SVG can save your day - Fronteers June 2022

By Louis Hoebregts

How SVG can save your day - Fronteers June 2022

Presentation made during the Fronteers Meetup on 26 June 2022.
